Asian
Asian Electron YK-PSW1270E 12VDC 700W Pure Sine Wave Inverter
$550.43
inc GST ▲
+GST
Free shipping over $299
Genuine product
7-day returns
Features
Asian Electron YK-PSW1270E 12VDC 700W Pure Sine Wave Inverter
Specifications
Technical Specifications
| Continuous Output Power | 700W |
|---|---|
| Maximum Output Power (3Min.) | 780W |
| Surge Rating | 1400W |
| Input Voltage | 12V |
| Input Voltage Range | 10.5-16 VDC |
| Output Voltage | 200/220 / 230 / 240V RMS ± 3% |
| Frequency | 50/60Hz ±0.05% (Switch Selectable) |
| Efficiency (full load) | 92% |
| No Load Current Draw | 0.83A |
| Output Waveform | Pure Sine Wave < THD 3% |
| Protection | Overload, Short Circuit, Reverse Polarity (Fuse), Over/Under Input Voltage, Over Temperature. |
| Digital Display | OVP, UVP, OTP, OLP, VAC, AMP, WATT, VDC, TEMP, Hz |
| Interface Control Port | RS-232C With Baud Rate 2400, 4800,9600,19200 (Switch Selectable) |
| Operating Temperature Range | 0-50ºC |
| Storage Temperature Range | -30ºC to 70ºC |
| Cooling | Loading controlled cooling fan |
| Dimensions | 298(L) x 179(W) x 81(H) mm |
| Weight | 2.8kgs |
| Warranty | 12 months |
| Brand | Asian |
|---|---|
| Product Type | Portable Power |
| Weight | 1.01 kg |
| Warranty |
|---|
