DBX
DBX DI4 ACTIVE 4 CHANNEL DIRECT BOX W/LINE MIXER
$403.57
inc GST ▲
+GST
Free shipping over $299
Genuine product
7-day returns
Features
DBX DI4 ACTIVE 4 CHANNEL DIRECT BOX W/LINE MIXER
Specifications
Technical Specifications
| Audio Input Connectors | 1/4" TS unbalanced |
|---|---|
| Input Impedance | 320kohm |
| Peak Input Level | +15 dBu |
| Headphone Connector | 1/4" stereo jack |
| Stereo Line Mixer Outputs | RCA connectors |
| XLR Balanced Outputs | XLR connectors |
| Output Impedance | 600ohm |
| Maximum Output Level | +16 dBu |
| Frequency Response | 20 Hz - 20 kHz, 0 dB to -2 dB |
| THD + Noise | 0.0008% typical at +4 dBu, 1 kHz |
| Interchannel Crosstalk | -90 dB (20 Hz - 20 kHz) |
| Power Supply | ~100-120 V AC / ~200-240 V AC, 50-60 Hz |
| Power Consumption | 775 mW |
| Dimensions (H x W x D) | 44.5 mm x 230.6 mm x 217 mm |
| Weight | Approx. 1.75 kg |
| Warranty | 12 months |
| Brand | DBX |
|---|---|
| Product Type | Pro Audio |
| Weight | 0.5 kg |
| Warranty |
|---|
