LevelOne
LevelOne IGU-0501 5-Port Gigabit Industrial Switch DIN-Rail -40 C to 75 C 1x SFP (Promotionalprice)
$112.17
inc GST ▲
+GST
Free shipping over $299
Genuine product
7-day returns
Features
LevelOne IGU-0501 5-Port Gigabit Industrial Switch DIN-Rail -40 C to 75 C 1x SFP (Promotionalprice)
Specifications
Technical Specifications
| Manufacturer part number | IGU-0501 |
|---|---|
| Brand | LevelOne |
| Manufacturer Part Number | IGU-0501 |
| Color | Black |
| Weight | 0.35 kg |
| Dimensions (W x D x H) | 99 x 65 x 50 mm |
| Gigabit RJ45 | 4 |
| Gigabit SFP | 1 |
| Power Redundancy | Dual Power Input |
| Features | MTBF: 400k Hours |
| Power supply | VDC 12~60V |
| Data Rate | 1Gbps |
| Power supply included | No |
| Power input | Redundant Dual DC 48V-57V |
| Power consumption | <5W |
| Standard | IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3z 1000Base-X Gigabit Ethernet IEEE802.3x Flow Control and Back |
| Mount | DIN rail mount |
| MAC address table | 8K |
| Indicators | Power Act/Link 10/100/1000 |
| Packet buffer | 1M |
| Backplane (Gbps) | 10 |
| Grade | Industrial |
| PoE Supported | No |
| Manageable | No |
| Fanless | Yes |
| Concurrent ports | Total 5.00 |
| Approval and Compliance | CE/FCC IEC61000-4-2(ESD: 6KV:contact / 8KV:air) IEC61000-4-5(Surge: 6KV) |
| Operating humidity | 0% RH ~ 95% RH |
| Operating temperature | 40°C ~ 75°C |
| Storage humidity | 0% RH ~ 95% RH |
| Storage temperature | 40°C ~ 85°C |
| Package Contents | IGU-0501 Quick Installation Guide |
| Product type | Network Accessories |
| Weight | 0.5 kg |
| Warranty | 12 months |
| Brand | LevelOne |
|---|---|
| Product Type | Network Accessories |
| Weight | 0.5 kg |
| Warranty |
|---|
