PreSonus MONITORSTATIONV2 STUDIO CTRL CENTER W SPDIF INPU

SKU: MONITORSTATIONV2 ● In Stock
$683.94
inc GST ▲ +GST
Free shipping over $299 Genuine product 7-day returns

You May Also Like

Features

PreSonus MONITORSTATIONV2 STUDIO CTRL CENTER W SPDIF INPU

Specifications

Technical Specifications

Gain Range: +15 to +55 dB
Type: Electret condenser
Sensitivity: -42 dB
Type: 1/4" TRS Active Balanced
Input Impedance: 10 kOhms (balanced)
S/N Ratio: (1 kHz @ +10 dBu, unity gain) >105 dB
THD+N: (unwtd, 1 kHz @ 0 dBu output, unity gain)
Frequency Response: (±0.5 dB) 10 Hz to 65 kHz
Noise Floor: (20 Hz to 20 kHz, 150Ohms input termination) -96 dBu
Maximum Input Level: (minimum gain, 1 kHz @ 0.5% THD+N) +22 dBu
Type: RCA active unbalanced
Input Impedance: 47.5 kOhms
S/N Ratio: (1 kHz @ 0 dBu, Unity Gain) >115 dB
THD+N: (unwtd, 1 kHz @ 0 dBu Output, Unity Gain)
Frequency Response: (±0.5 dB) 10 Hz to 50 kHz
Gain Range: 80 dB to +10 dB
Type: RCA 75Ohms coax
Dynamic Range: 113 dB
THD+N: 0.0025% (1 kHz @ -1 dBFS)
Maximum Output: at 0 dBFS +18 dBu
Sample Rates: 44.1, 48, 88.2, 96 kHz
Type: Dual 8-segment LED w/peak hold
Sensitivity Range: -24 dB to 0 dB
Type: 1/4" TRS active balanced
Output Impedance: 51Ohms (balanced)
THD+N: (unwtd, 1 kHz @ 0 dBu, unity gain)
Frequency Response: (±0.5 dB) 10 Hz to 50 kHz
Trim Range: -80 dB to 0 dB
Main Level Range: -80 dB to 0 dB
Dim Attenuation Range: -30 dB to -6dB
Cue Level Range: -80 dB to 0 dB
Dim Attenuation: (talkback activated) -20 dB
Type: 1/4" TRS active stereo
Maximum Output: (60Ohms load) 150 mW / channel
Frequency Response: (±1.0 dB) 10 Hz to 50 kHz
Power Supply Type: External DC transformer/internal line
Input Connector Type: Barrel, 5.5 mm outside diameter, 2.1 mm inside diameter
Monitor Station Input Voltage Range: 18 VDC
Power Requirements: (continuous) 10W
Physical Dimensions: 2.5 x 8.5 x 9.0" (63.5 x 216.0 x 228.6 mm)
Weight 6 lb (4.54 kg)
Warranty 12 months
