Smartoptics SOSFP1G-BX10D53
Smartoptics SOSFP1G-BX10D53
Smartoptics SOSFP1G-BX10D53
Smartoptics

Smartoptics 1.25G SFP BiDi LC Simplex Transceiver Module for SingleMode Fibre. Dual Wave length TX/RX 1550/1310nm, DDM, 10km, 12dB Industrial Temp -40C to 85C

SKU: SOSFP1G-BX10D53 ● In Stock
$103.48
inc GST ▲ +GST
Free shipping over $299 Genuine product 7-day returns

You May Also Like

Features

Smartoptics 1.25G SFP BiDi LC Simplex Transceiver Module for SingleMode Fibre. Dual Wave length TX/RX 1550/1310nm, DDM, 10km, 12dB Industrial Temp -40C to 85C

Specifications

Technical Specifications

Manufacturer part number SOSFP1G-BX10D53
Technology BiDi SFP
Transmitter Data Output Power Min: -9.0 dBm Max: -3.0 dBm Tx Wavelength: 1270 - 1350 nm* 1500 - 1580 nm **
Transmission Media SM (1x LC)
Typical Reach 10 km
Nominal Wavelength 1310 nm * & 1550 nm **
Bit Rate Range 1.063 / 1.25 Gbps
Protocols Eth: GbE FC: 1G FC
Receiver Data Minimum Input Power: -21.0 dBm*** Overload (max power): -3.0 dBm Wavelength Range: 1530 - 1570 nm*, 1260 - 1360 nm**
Power Budget 0.0 - 12.0 dB ***
Notes *SO-SFP-1000Base-BX10D-35 **SO-SFP-1000Base-BX10D-53 ***GbE
Temperature Range 0°C to +70°C; -40°C to +85°C (-I)
DDM Yes
MSA Compliance SFP MSA, SFF 8472
Power Consumption < 1.0W
Regulatory Compliance EMC: CE EN 55022:2010, EN 55024:2010 UL/Safety: UL 60950-1 FCC: 47 CFR PART 15 OCT, 2013 RoHS: RoHS 6 TUV: EN 60950-1:2006+A11+A1+A12+A2 EN 60825-1:2014 EN 60825-2:2004+A1+A2
Product type Network Accessories
Weight 0.5 kg
Warranty 12 months
