StarTech.com
StarTech.com 6830054 USB-C to Dual-DP Multiport Hub 100W
$119.87
inc GST ▲
+GST
Free shipping over $299
Genuine product
7-day returns
Features
StarTech.com 6830054 USB-C to Dual-DP Multiport Hub 100W
Specifications
Technical Specifications
| Manufacturer part number | 189B-USBC-MULTIPORT |
|---|---|
| External Ports | 2 - USB 3.2 Type-A (9 pin, Gen 1, 5Gbps) 3 - USB 3.2 Type-C (24 pin, Gen 1, 5Gbps) 1 - USB Type-C (24 pin) USB Power Delivery Only 1 - USB 2.0 Type-A (4 pin, 480Mbps) 2 - DisplayPo |
| Host Connectors | 1 - USB 3.2 Type-C (24 pin, Gen 1, 5Gbps) |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | 10°C to 70°C (50°F to 158°F) |
| Humidity | 10% ~ 85% RH (non-condensing) |
| 4K Support | Yes |
| Displays Supported | 2 |
| # of Displays Supported | 2 |
| Interface | USB 3.2 Gen 1 (5Gbps) |
| Bus Type | USB-C |
| Industry Standards | DisplayPort 1.2 USB 3.2 Gen 1 (5Gbps) USB Power Delivery Specification Rev. 3.0 |
| Chipset ID | Synaptics - VMM5220 VIA - VL103 VIA - VL817S Realtek - RTL8153E |
| Wake On Lan | Yes |
| Maximum Digital Resolutions | 4K 60Hz |
| Type and Rate | USB 5Gbps |
| UASP Support | Yes |
| PXE | Yes |
| Full Duplex Support | Yes |
| MTBF | 103,855 Hours |
| Color | Space Gray |
| Material | Plastic |
| Cable Length | 12.0 in [30.5 cm] |
| External Ports | 2 - USB 3.2 Type-A (9 pin, Gen 1, 5Gbps) 3 - USB 3.2 Type-C (24 pin, Gen 1, 5Gbps) 1 - USB Type-C (24 pin) USB Power Delivery Only 1 - USB 2.0 Type-A (4 pin, 480Mbps) 2 - DisplayPo |
| Host Connectors | 1 - USB 3.2 Type-C (24 pin, Gen 1, 5Gbps) |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | 10°C to 70°C (50°F to 158°F) |
| Humidity | 10% ~ 85% RH (non-condensing) |
| 4K Support | Yes |
| Displays Supported | 2 |
| # of Displays Supported | 2 |
| Interface | USB 3.2 Gen 1 (5Gbps) |
| Bus Type | USB-C |
| Industry Standards | DisplayPort 1.2 USB 3.2 Gen 1 (5Gbps) USB Power Delivery Specification Rev. 3.0 |
| Chipset ID | Synaptics - VMM5220 VIA - VL103 VIA - VL817S Realtek - RTL8153E |
| Wake On Lan | Yes |
| Maximum Digital Resolutions | 4K 60Hz |
| Type and Rate | USB 5Gbps |
| UASP Support | Yes |
| PXE | Yes |
| Full Duplex Support | Yes |
| MTBF | 103,855 Hours |
| Color | Space Gray |
| Material | Plastic |
| Cable Length | 12.0 in [30.5 cm] |
| Product Length | 5.9 in [150 mm] |
| Product Width | 2.2 in [55 mm] |
| Product Height | 0.6 in [16.5 mm] |
| Weight of Product | 0.3 lb [0.1 kg] |
| Power Source | Bus Powered and Host USB-C Power Adapter |
| Power Delivery | 100W |
| Output Voltage | 5 DC |
| Plug Type | USB Type-C (24 pin) USB Power Delivery Only |
| Power Consumption (In Watts) | 15W |
| OS Compatibility | Windows 10, 10 ARM, 11, 11 ARM Linux ChromeOS |
| System and Cable Requirements | A host device with an available USB-C port (to ensure full adapter functionality, the host device's USB-C port must support USB Power Delivery and DP alt mode). Optional: USB-C pow |
| Note | Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery and DP alt mode. If the USB-C Host does |
| Included in Package | 1 - Multiport Adapter 1 - Product Documentation |
| Product type | USB Hubs |
| Weight | 0.2 kg |
| Warranty | 12 months |
| Brand | StarTech.com |
|---|---|
| Product Type | USB Hubs |
| Weight | 0.2 kg |
| Warranty |
|---|
