StarTech.com DP14VMM4M 8K 60Hz - VESA Certified DisplayPort Cable - 4m (13ft)

SKU: DP14VMM4M ● In Stock
$70.43$76.13
inc GST ▲ +GST
Free shipping over $299 Genuine product 7-day returns

Features

This DisplayPort 1.4 cable connects your DisplayPort™ laptop or desktop computer to an ultra-high definition 8K monitor, TV or projector. It supports resolutions up to 8K (7680 x 4320) at 60Hz.

The DisplayPort monitor cable provides the essential connection to support the next generation of ultra-high definition video.

This cable is VESA® to ensure full compliance and efficient operation of the higher link rate of HBR3. It has been tested to meet all DP 1.4 specifications to ensure quality and reliability.

The Superior Performance of DisplayPort 1.4

This 8K DisplayPort cable supports all DP 1.4 features:

- High Bit Rate 3 (HBR3) Bandwidths of 32.4 Gbps supporting the latest in industry standards
- High Dynamic Range (HDR10) for higher contrast ratio and vivid colors
- Multi-Stream Transport (MST) for daisy-chaining multiple monitors
- Display Stream Compression 1.2 (DSC) for maximum resolution output
- Forward Error Correction to manage data transmission errors
- High-Bandwidth Digital Content Protection (HDCP 2.2) for a secure connection between source and display
- 32 Uncompressed Digital Audio Channels

Cable Key Features

Aluminum-mylar foil with braided shielding improve EMI protection
Long lasting flexible TPE jacket & strain relief (TPE is non-toxic & halogen free for environmental sustainability)

Connector Key Features

Die-cast aluminium sub-structure shielding improves signal integrity & prevents signal degradation
Corrosion-free gold-plated connectors ensure premium video quality & enhanced reliability
Tested to withstand 5000+ insertions

8K: Enabling Business Continuity

8K has a resolution of 7680 x 4320 and is also known as 4320p and Ultra High Definition (UHD). Suitable for digital signage and other commercial displays that require the highest available resolution. This cable is backward compatible with 4K and 5K displays making it the perfect peripheral to start futureproofing your cabling infrastructure.

Specifications

Technical Specifications

1 - Connector A DisplayPort (20 pin)
1 - Connector B DisplayPort (20 pin)
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature 0°C to 50°C (32°F to 122°F)
Humidity 0%RH ~ 85%RH
Active or Passive Adapter Passive
Number of Conductors 19
Connector Plating Gold
Cable Jacket Material TPE - Thermoplastic Elastomers
Cable Shield Material Aluminum-Mylar Foil with Braid
Shipping (Package) Weight 323.0 g [11.4 oz]
Package Height 2.3 cm [0.9 in]
Package Length 33.0 cm [13.0 in]
Package Width 24.5 cm [9.6 in]
Maximum Data Transfer Rate 32.4Gbps
Maximum Digital Resolutions 8K 60Hz (7680 x 4320)
Audio Specifications DisplayPort - 7.1 Channel AudioDisplayPort - 5.1 Channel Audio
Color Gray and Black
Product Height 1.3 cm [0.5 in]
Weight of Product 309.0 g [10.9 oz]
Product Width 2.0 cm [0.8 in]
Product Length 4.0 m [13.1 ft]
Wire Gauge 28 AWG
Cable Length 4 m [13.1 ft]
Cable OD 7.5 mm [0.3 in]
