StarTech.com UVCHDCAP - HDMI to USB C Video Capture Device
Features
This HDMI® to USB-C™ video capture device lets you record HDMI video to your USB-C, USB-A or Thunderbolt™ 3 computer.
- Hassle-free USB-C HDMI capture using the UVC video standard and plug-and-play installation
- Live broadcast your video source over the internet, with support for live streaming
- Maintain the HD picture quality of your source content (maximum resolution 1080p at 60fps)
Easy Setup, Easy Capture
For hassle-free recording, you can install the HDMI capture device by simply connecting it to your computer. The capture device features USB Video Class (UVC), a video capture standard that's natively supported by Mac, Windows® and Linux®. Unlike other capture devices that require proprietary driver installation, UVC based capture devices install automatically for a truly plug-and-play solution. Also, with this recorder you're not limited to the included software; you can use any third-party software that uses UVC compatible frameworks such as Quicktime or DirectShow®.
Capture HD Video
Record 1080p video at 60fps (frames per second) from your Windows PC, gaming console, camera (and more) so you can save, share or edit your content. Capture meetings, presentations, conference calls and security footage directly to your computer.
Stream Your 1080p Content
Stream video over the web using Twitch™ or other third-party streaming platforms. With the included software or third-party UVC compatible software like Open Broadcaster Software (OBS), you can live broadcast video over the internet using third-party video streaming platforms.
The UVCHDCAP is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Note: This device is HDCP compliant, and will not capture copy protected video, such as Blu-rays or the video output of Mac computers. However, this device will capture video to Mac computers and will capture non-encrypted video.
Applications
- Capture meetings, presentations or conference calls directly to your computer
- Upload recorded videos or live broadcast your signal to any online video platform
- Record training and tutorial videos from your laptop or game console
Specifications
Technical Specifications
| Audio | Yes |
|---|---|
| AV Input | HDMI |
| AV Output | USB |
| Chipset ID | Mstar - MST3363CNK-170 |
| Industry Standards | MPEG4 (H.264)USB Video Class (UVC) |
| Audio Specifications | 2-channel stereo audio |
| Maximum Digital Resolutions | 1920 x 1080 60 FPS |
| Supported Resolutions | 1920 x 1080, 1280 x 720, 1024 x 768, 800 x 600 |
| Wide Screen Supported | Yes |
| Connector A | 1 - HDMI (19 pin) Female Input1 - 3.5 mm Mini-Jack (3 Position) Female Input |
| Connector | B 1 - USB Type-B (9 pin) USB 3.0 Female |
| OS Compatibility | Windows® 7, 8, 8.1, 10MacOS® 10.11 to 10.14Linux 4.x (LTS Versions only) |
| Humidity | 20-80% RH Non-Condensing |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -5°C to 40°C |
| Color | Silver & Black |
| Product Height | 15.4 in [39.2 cm] |
| Product Length | 8.5 in [21.5 cm] |
| Product Width | 2.4 in [60 mm] |
| Weight of Product | 2.8 oz [80 g] |
| Brand | StarTech.com |
|---|---|
| Product Type | TV & Home Theatre > TV/Video Capture |
| Weight | 0.068 kg |
| Warranty |
|---|
