StarTech.com SV211HDUC - 2 Port USB-C Alt-Mode Compact KVM Switch
Features
This 2-port USB-C KVM enables you to easily switch between two USB Type-C or Thunderbolt 3 desktop or laptop computers, using a single keyboard, HDMI monitor and mouse.
Easy to Setup and Use
Utilizing USB-C with DP alt-mode, this compact KVM switch only requires a single cable be connected to each of your computers, ensuring a small footprint with limited cabling requirements. All required cables for connecting your computers are included, to ensure a hassle-free setup right out of the box.
For easy operation, the KVM features a single button that toggles between connected computers.
Supports 4K 60Hz Resolutions
The USB-C KVM switch supports UHD resolutions up to 4K (3840x2160) at 60Hz and can drive one large HDMI 2.0 display with ease, maximizing viewing space.
Compact and Portable
Along with the USB-C design that ensures cabling requires are minimum the KVM is bus powered further reducing clutter by avoiding the need for a bulky power adapter. The lightweight small form factor makes this mini KVM switch easy to deploy and is ideal for mobile/hot desk workforces.
Guaranteed Compatibility
The KVM is OS independent supporting all operating systems including Windows, Linux, macOS, iPadOS (Apple iPad Pro) and Android. StarTech.com has rigorously tested this product to ensure compatibility with all popular device brands including: Dell, HP, Apple and Lenovo.
Applications
- High resolution medical imaging
- Digital signage server control
- Mobile and hot-desk work forces
For more information: https://www.startech.com/en-us/server-management/sv211hduc
Specifications
Technical Specifications
| Console Interface(s) | 2 x USB Type-A (4 pin) USB 2.0 |
|---|---|
| Console Interface(s) | 1 x HDMI (19 pin) |
| Host Connectors | 2 x USB Type-C (24-pin) USB 2.0 (480Mbps) |
| Operating Temperature | 5°C ~ 35°C |
| Storage Temperature | -20°C ~ 50°C |
| Humidity | 20%RH ~ 80%RH |
| Audio | Yes |
| KVM Ports | 2 |
| PC Interface | USB-C |
| PC Video Type | USB-C (DP Alt-Mode) |
| Number of Monitors Supported | 1 |
| Rack-Mountable | No |
| Cables Included | Yes |
| Chipset ID | Parade - PS176VLI - VL170Terminus - FE1.1S |
| Daisy-Chain | No |
| Video Revision | DisplayPort 1.2 |
| On-Screen Display | No |
| Video Revision | HDMI 2.0 |
| IP Control | No |
| Hot-Key Selection | No |
| Maximum Data Transfer Rate | 480Mbps |
| Wide Screen Supported | Yes |
| Audio Specifications | HDMI - 7.1 Channel Audio |
| Port Selection Support | Push Button |
| MTBF | 50,000 hours |
| Colour | Black |
| Product Length | 72.0 mm [2.8 in] |
| Product Width | 14.0 cm [5.5 in] |
| Weight of Product | 265.0 g [9.4 oz] |
| Product Height | 15.7 mm [0.6 in] |
| Material | Plastic |
| Power Source | Bus Powered |
| System and Cable Requirements | Your USB-C ports must support DisplayPort over USB-C (DP Alt mode) in order to work with this KVM switch |
| Brand | StarTech.com |
|---|---|
| Product Type | PC Peripherals > KVM Switches & Cables |
| Weight | 0.204 kg |
| Warranty |
|---|
