StarTech.com ICUSB2328I 8 Port USB to DB9 RS232 Serial Adapter Hub Industrial DINRail and Wall Mountable - USB to RS 232
Features
8 Port USB to DB9 RS232 Serial Adapter Hub - Industrial DIN Rail and Wall Mountable
The ICUSB2328I Industrial 8-Port USB to Serial Hub with DIN Rail Clips converts a single USB port into eight RS232 serial ports, enabling you to connect to, monitor and control your serial devices. Featuring rugged metal construction, with sturdy wall-mounting brackets and top-hat DIN Rail clips (included), this 8 port USB to RS232 Serial Hub provides versatile mounting options and a robust solution for both harsh industrial environments and simple desktop installations. This USB powered adapter also retains assigned serial COM port values once connected, allowing the same values to be automatically reassigned to the USB serial hub ports. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Integrated wallmount brackets and included DIN Rail clips for versatile mounting options
- Rugged all-metal enclosure for added durability in harsh environments
- Easy plug and play installation, with our USB Powered adapter - no power outlet required
Specifications
Technical Specifications
| Bus Type | USB 2.0 |
|---|---|
| Chipset ID | FTDI - FT232RL |
| Interface | Serial |
| Port Style | External Hub |
| Ports | 8 |
| Data Bits | 7, 8 |
| FIFO | 4096 byte Transmit and Receive |
| Max Baud Rate | 921.6 Kbps |
| Maximum Data Transfer Rate | 921.6 Kbps |
| MTBF | 146,300 Hours |
| Parity | Odd, Even, Mark, Space, None |
| Serial Protocol | RS-232 |
| Stop Bits | 1, 2 |
| External Ports | 1 - USB B (4 pin) Female8 - DB-9 (9 pin, D-Sub) Male |
| OS Compatibility | Windows® CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016Mac OS® 10.6 to 10.12Linux 2.4.x to 4.4.x LTS Versions only |
| LED Indicators | 8 - Each, Tx/Rx Activity indicators |
| Input Current | 250 mA |
| Input Voltage | 5 DC |
| Plug Type | M |
| Power Source | USB-Powered |
| Humidity | 5~95% RH |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -20°C to 85°C (-4°F to 185°F) |
| Included in Package | 1 - USB to RS-232 Serial Adapter1 - DIN rail kit1 - 6 ft USB A to B cable1 - Driver CD1 - Instruction Manual |
| Brand | StarTech.com |
|---|---|
| Product Type | PC Peripherals > Adapters |
| Weight | 0.9 kg |
| Warranty |
|---|
