ATW1701-L-KIT - AUDIO TECHNICA DSLR CAMERA MOUNT DIGITAL WIRELESS LAPEL MICROPHONE SYSTEM 2.4GHZ
You May Also Like
Sansai IPH-266E Stereo Earphone with built-in Microphone 3.5mm stereo plug
Features
System 10 Camera Mount
With its compact and portable design, the System 10 Camera-Mount high-fidelity digital wireless system is ideally positioned to capture media on the go. Perfect for video production, electronic news gathering (ENG) and every mobile application in between, the receiver features multiple mounting options to accommodate a variety of cameras and recording devices.
- Digital 24-bit/48 kHz wireless operation for ultimate sound quality and dependable performance
- Operates in the 2.4 GHz range - completely free from TV interference
- Ultra compact receiver size with multiple mounting options
- Selectable balanced and unbalanced output jacks with level control for use with most cameras and recording devices
- Internal rechargeable 12-hr battery
- Separate headphone port and volume control for local audio monitoring
- Multi-pairing function to link a single receiver with up to eight body-pack or handheld transmitters
- Three levels of diversity assurance: frequency, time & space
Provides three levels of diversity assurance: frequency, time and space
Like all of the products in the System 10 digital wireless family, the Camera Mount provides three levels of diversity assurance: frequency, time and space. Instantaneous channel selection, sync and setup make the Camera-Mount extremely easy to use, while its digital 24-bit/48 kHz wireless operation provides the ultimate in sound quality and dependable performance. Also, as the receiver operates in the 2.4 GHz range, it remains completely free from TV interference at all times.
Specifications
Technical Specifications
| Operating Frequencies | 2.4 GHz ISM band (2400 to 2483.5 MHz) |
|---|---|
| Dynamic Range | >109 dB (A-weighted), typical |
| Total Harmonic Distortion | <0.05% typical |
| Operating Range | 30 m (100') radius, 60 m (200') diameter typicalOpen range environment with no interfering signals |
| Operating Temperature Range | 0° C to +40° C (32° F to 104° F)Battery performance may be reduced at very low temperatures |
| Frequency Response | 20 Hz to 20 kHzDepending on microphone type |
| Maximum Simultaneous Use (Recommended) | 200' minimum |
| Audio Sampling | 24 bits / 48 kHz |
| Receiving System | Diversity (frequency/time/space) |
| Maximum Output Level | 3.5 mm (1/8"), TRS balanced: +6 dBV Dual mono, unbalanced: 0 dBV |
| Power Supply | 100-240V AC (50/60 Hz)to 5V DC 0.5A switched mode external USB-type external power supply |
| Internal Battery | 3.7V rechargeable Li-ion batteryBattery Rating: 5.5 Wh1,460 mAh |
| Battery Life | 12 hoursDepending on environmental conditions |
| Battery Charging Time | Up to 4 hours 30 minutes |
| Charging Temperature Range | 5° C to +35° C (41° F to 95° F) |
| Operating Temperature Range | 40° F (4° C) to 110° F (43° C) |
| Dimensions | 56.0 mm W x 91.4 mm H x 27.8 mm D |
| Net Weight | 105 grams (3.7 oz) |
| Accessories Included | Two antennas; camera shoe mount; AC adapter (USB-type);USB cable; 3.5 mm (1/8") stereo cable |
| RF Power Output | 10 mW |
| Spurious Emissions | Following federal and national regulations |
| Input Connections | Four-pin Locking ConnectorPin 1: GND, Pin 2: INST INPUT,Pin 3: MIC INPUT, Pin 4: DC BIAS +9V |
| Batteries | Two 1.5V AA ,not included |
| Battery Life | >7 hours (alkaline)Depending on battery type and use pattern |
| Dimensions | 70.2 mm W x 107.0 mm H x 24.9 mm D |
| Net Weight | 100 grams (3.5 oz)without batteries |
| RF Power Output | 10 mW |
| Spurious Emissions | Following federal and national regulations |
| Batteries | Two 1.5V AAnot included |
| Battery Life | Up to 7 hours (alkaline)Depending on battery type and use pattern |
| Dimensions | 254.8 mm (10.03") long,50.0 mm (1.97") diameter |
| Net Weight | 280 grams (9.9 oz)without batteries |
| Accessory Included | AT8456a Quiet-Flex stand clamp |
| Brand | AUDIO TECHNICA |
|---|---|
| Product Type | Headphones & Audio > Pro Audio & Sound Recording > Microphones |
| Weight | 1.01 kg |
| Warranty |
|---|
