Brother TD4520DN - THERMAL DIRECT LABEL PRINTER - 300 DPI

Overview

Using direct thermal print technology, accurate images with crisp definition is created. Great for printing high-volume, temporary labels with barcodes. The length of media is automatically calculated with the media calibration function. Removing the need of manually entering label dimensions. With network connectivity, data is quickly shared with different departments. Make the TD-4520DN bespoke to your needs with a range of accessories including a peeler and cutter.

Network connectivity
Professional quality up to 300dpi print resolution
Fast print speeds up to 6 inches per second
Print width up to 4.27 inches / 108mm
Easy set-up with automatic media configuration
Ready to integrate with iOS and Android apps

Technical Specifications

Print technology	Direct thermal
Colour	N
Maximum resolution	300 x 300
Print speed	203
Print speed	6
Minimum print length	17
Mirror printing	Y
Text style	Bold,Horizontal lines,Invert,Italic,Normal,Shadow,Shadow light,Surround
Maximum print length	3
Maximum label width	118
Maximum roll diameter	127
Core diameter	12.7
Connectivity technology	Wired
Ethernet LAN	Y
Wi-Fi	N
Bluetooth	N
USB port	Y
USB 2.0 ports quantity	1
RS-232 ports	1
Page description languages	CPCL-native,DPL,EPL2,ESC P,Raster_P,ZPL II
Internal memory	256
Flash memory	64
Built-in barcodes	CODABAR (NW-7),Code 39,Code 93,Code-128 Codabar Library,EAN13,EAN8,GS1 DataBar,ITF,POSTNET,UPC-A,UPC-E
Number of fonts	6
Font styles	Brougham,Brussels,Helsinki,Letter Gothic,San Diego
Product colour	Grey,White
Built-in display	N
Display	N
Auto power off	Y
Windows operating systems supported	Windows 10,Windows 7,Windows 8,Windows 8.1
Server operating systems supported	Windows Server 2008,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016
Mobile operating systems supported	Android 4.1,Android 4.2,Android 4.2.1,Android 4.2.2,Android 4.3,Android 4.4,Android 5.0,Android 5.1,Android 6.0,Android 7.0,Android 7.1,Android 7.1.2,Android 8.0,Android 9.0,iOS 10.0,iOS 11.0,iOS 12,iOS 8.0,iOS 8.1,iOS 8.2,iOS 8.3,iOS 8.4,iOS 9.0,iOS 9.1,iOS 9.2,iOS 9.3
Linux operating systems supported	Y
Operating relative humidity (H-H)	5 - 40
Storage relative humidity (H-H)	20 - 85
Operating temperature (T-T)	10 - 90
Storage temperature (T-T)	-20 - 60
Width	265
Depth	335
Height	258
Weight	3041
Quantity per pack	1
Package weight	3965
Cables included	AC,USB
Quick start guide	Y
Warranty card	Y
AC adapter included	Y
Software development kit (SDK)	Y
Starter roll included	Y
Harmonized System (HS) code	84433210
Pallet gross height	144
Pallet gross weight	176400
Master (outer) cases per pallet	40
Master (outer) cases per pallet layer	8
Layers per pallet	5
Products per pallet	40
Pallet type	800 x 1200 mm
Networking features	10/100BASE-TX
LED indicators	Error,Power,Status
Country of origin	China
Languages support	CHI (SIMPL),CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,HUN,ITA,JPN,NOR,POL,POR,RUS,SWE,TUR
Date & time printing	Y
Number of languages	18
