Brother TD4520TN - THERMAL DIRECT TRANSFER LABEL PRINTER

Brother

Brother TD4520TN - THERMAL DIRECT TRANSFER LABEL PRINTER

Name: Brother TD4520TN - B2B - Office Equipment | KW Tech NZ
Brand: Brother
SKU: TD4520TN
Price: 797.67 NZD
Availability: InStock

SKU: TD4520TN ● In Stock

$797.67

Free shipping over $299 Genuine product 7-day returns

📄 Download Official Datasheet (PDF)

Brother TD4520TN - THERMAL DIRECT TRANSFER LABEL PRINTER

Overview

The TD-4520TN creates high resolution labels that last. Thermal transfer technology means labels are especially durable, making them suitable for a wide range of tasks in sectors like transport and logistics, retail, healthcare and food traceability. Operation is easy with BarTender and SAP compatibility*, and auto media configuration delivers better usability. For a more cost-efficient print option, direct thermal technology is built-in too, letting you print high-quality receipts, shipping labels and tickets.

300dpi high resolution printing for crisp text and barcodes
Thermal transfer print using high capacity ink ribbons
Up to 127mm/second (5 ips) print speed
USB, wired ethernet and serial ports as standard
Supports popular printer languages including ZPL/ZPL2, EPL and DPL
Free label design software available via download

Technical Specifications

Print technology	Direct thermal / thermal transfer
Colour	N
Maximum resolution	300 x 300
Print speed	127
Maximum print height	105
Maximum print length	11.43
Maximum label width	112
Maximum roll diameter	127
Core diameter	25.4
Connectivity technology	Wired
Ethernet LAN	Y
Wi-Fi	N
Bluetooth	N
USB port	Y
USB 2.0 ports quantity	2
RS-232 ports	1
Page description languages	DPL,EPL,ZPL,ZPL II
Internal memory	64
Flash memory	128
Built-in barcodes	AZTECCODE,CODABAR (NW-7),Code 128 (A/B/C),Code 39,Code 49,Code 93,EAN128,EAN13,EAN8,GS1 DataBar,ITF-14,Interleaved 2/5,MaxiCode,MicroPDF417,PDF417,POSTNET,QR Code,UPC-A,UPC-E
Number of fonts	8
Product colour	Black
Built-in display	N
Display	N
AC input voltage	100 - 240
AC input frequency	50 - 60
AC adapter output current	2
Windows operating systems supported	Windows 10,Windows 7,Windows 8,Windows 8.1
Mac operating systems supported	Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra,Mac OS X 10.14 Mojave
Server operating systems supported	Windows Server 2008,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016
Linux operating systems supported	Y
Operating relative humidity (H-H)	5 - 40
Storage relative humidity (H-H)	25 - 85
Operating temperature (T-T)	10 - 90
Storage temperature (T-T)	-40 - 60
Width	275
Depth	405
Height	245
Weight	3148
Quantity per pack	1
Package weight	3927
Cables included	AC,USB
Quick start guide	Y
Warranty card	Y
AC adapter included	Y
Software development kit (SDK)	Y
Starter roll included	Y
Harmonized System (HS) code	84433210
Pallet gross height	162
Pallet gross weight	211920
Master (outer) cases per pallet	48
Master (outer) cases per pallet layer	8
Layers per pallet	6
Products per pallet	48
Pallet type	800 x 1200 mm
LED indicators	Y
Country of origin	China
Languages support	DAN,DEU,DUT,ENG,ESP,FIN,FRE,ITA,NOR,POR,SWE
Number of languages	11
Spare part retention	5
