Cambium Networks C024900C612 - Cambium ePMP 2.4 GHz Force 130 Point to Point, Wireless CPE Radio
Cambium Networks C024900C612 - Cambium ePMP 2.4 GHz Force 130 Point to Point, Wireless CPE Radio
Features
The Cambium Networks' ePMP™ 2.4 GHz Force 130 is an affordable WISP subscriber module particularly well-suited for markets where price is key.
Wireless service providers and enterprises around the globe are challenged to deliver reliable connectivity in overcrowded RF environments. As spectrum increasingly becomes a scarce commodity, finding the right broadband connectivity solution is vital for all low and high density types of deployments.
- Designed to operate in high interference environments and provides throughput of up to 140 Mbps with bi-directional traffic of real user data
- Configurable Modes of operation ensure robust adaptivity to both symmetrical and asymmetrical traffic while providing high performance and low round-trip latency
- QoS management offers outstanding quality for triple play services - VoIP, video and data and provides three levels of traffic priority
- Installation is a breeze for pole and wall mounting
- The ePMP Force 130 is compatible with ePMP 1000 Access Points
- Integrated 12 dBi 2.4GHz antenna
Specifications
Technical Specifications
| Frequency Range | 2402 - 2472 MHz |
|---|---|
| Channel Width | 5/10/20/40 MHz |
| MAC (Media Access Control) Layer | Cambium Proprietary |
| Physical Layer | 2x2 MIMO/OFDM |
| Ethernet Interface | 10/100 BaseT |
| Network Management | HTTPs, SNMPv2c, SSH |
| VLAN | 802.1Q with 802.1p priority |
| Transmit Power Range | +3 to 31 dBm (combined, to regional EIRP limit) (1 dB interval) |
| Antenna Gain | 12 dBi |
| 3dB Beamwidth-Azimuth | 45 degrees |
| 3dB Beamwidth-Elevation | 15 degrees |
| Environmental | IP55 |
| Temperature | -30°C to +55°C |
| Weight | 0.35 kg |
| Wind Survival | 125 km/hour |
| Dimensions (H x W x D) | 235 x 77 x 58 mm |
| Pole Diameter Range | 38mm - 64mm |
| Power Consumption | 8 W Maximum, 5 W Typical |
| Input Voltage | 24 V; uses standard passive PoE injectors at 24V. Not compatible with 29V supplies |
Not happy? Return within 7 days of delivery for a full refund or exchange. Items must be unused and in original packaging. Contact contact@kwtech.co.nz to arrange.
| Brand | Cambium Networks |
|---|---|
| Product Type | B2B - Networking & Routing |
| Weight | 0.5 kg |
