Cisco CS-ROOM55-FSK=
Cisco CS-ROOM55-FSK=
Cisco

Cisco UCS-CPU-6146 3.2 GHz 6146/165W 12C/ 24.75MB Cache/DDR4 2666MHz

SKU: CS-ROOM55-FSK= ● In Stock
$2,146.96
inc GST ▲ +GST
Free shipping over $299 Genuine product 7-day returns

You May Also Like

Cisco

Cisco MGBSX1 Gigabit SX Mini-GBIC SFP Transceiver

$159.13
inc GST ▲ +GST
CISCO

CISCO DBS-210-3PC-AU-K9 Cisco IP DECT Base Station 210 Series 3PCC AU and NZ

$918.26
inc GST ▲ +GST
CISCO

CISCO IW-ANT-OMV-2567-N 2.4/5/6 GHz 7dBi Omni Vertical Polarized Antenna N Conn

$688.70
inc GST ▲ +GST
CISCO

CISCO C9K-ADPT-BRKT-12T Power adaptor bracket for 12T compact switches spare

$41.74
inc GST ▲ +GST
CISCO

CISCO CAB-L240-10-SM-TM 10-ft3M Ultra Low Loss LMR240 Cable with SMA/TNC Connector

$280.00
inc GST ▲ +GST

Features

Cisco UCS-CPU-6146 3.2 GHz 6146/165W 12C/ 24.75MB Cache/DDR4 2666MHz

Specifications

Technical Specifications

Manufacturer part number CS-ROOM55-FSK=
Optional hardware components Microphone extension cable HDMI presentation cable 8m/26.2 ft.
Bandwidth Up to 6 Mbps point-to-point
Minimum bandwidth for resolution/frame r H.264: 720p30 from 768 kbps 720p60 from 1152 kbps 1080p30 from 1472 kbps 1080p60 from 2560 kbps
Firewall traversal Cisco Expressway ™ technology H.460.18, H.460.19 firewall traversal
Video standards H.264 H.265
Video inputs Two HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps, including HD1080p60; HDMI 2 supports HDCP content for local viewing Consumer Electronics Control (CEC) 2.0
Video outputs One HDMI output supports formats up to 3840 x 2160 at 60 fps (4Kp60) Live video resolutions (encode and decode) up to 1920 x 1080 at 30, 60 fps (HD1080p) Consumer Electronics Contr
Audio standards G.711, G.722, G.722.1, G.729, AAC-LD, and Opus
Audio features High-quality 20-kHz audio Prepared for inductive loop (line out) Automatic Gain Control (AGC) Automatic noise reduction Active lip synchronization
Audio inputs Two microphones, 4-pin minijack Two audio in from HDMI Internal microphone
Audio outputs (external) 1 line out minijack (stereo)
Speakers (integrated) High-quality speaker system with left, center, and right channels, plus woofer Frequency response 70 Hz to 20 kHz Amplifier power: 80W Max output level SPL 98 dB
Speaker tracking 6-element microphone array for accurate speaker tracking
Display 55 in. (1.4m) LCD monitor, LED backlight Resolution: 3840 x 2160 (16:9) Contrast ratio: typical 1100 Viewing angle: +/- 178 degrees Response time: typical 8 ms Brightness: typical
Dual stream H.239 (H.323) dual stream Binary Floor Control Protocol (BFCP) (SIP) dual stream Supports resolutions up to 3840 x 2160 at 5 fps
Wireless sharing Cisco Webex app (up to 3840 x 2160 at 5 fps) Cisco Intelligent Proximity client (up to 1920 x 1080 at 5 fps)
Multipoint support 4-way embedded SIP/H.323 conferencing capability with MultiSite option
MultiSite features (embedded multipoint) Adaptive SIP/H.323 MultiSite: 3-way resolution up to 1080p30 + content up to 4Kp5 4-way resolution up to 720p30 + content up to 4Kp5 Full individual audio and video transcoding H.3
Protocols H.323 SIP Cisco Webex
Embedded encryption H.323 and SIP point-to-point Standards-based: H.235 v3 and Advanced Encryption Standard (AES) Automatic key generation and exchange
IP network features DNS lookup for service configuration Differentiated services (Quality of Service [QoS]) IP-adaptive bandwidth management (including flow control) Automatic gatekeeper discovery Dyn
Call control Cisco Unified Communications Manager (CUCM) Native registration with CUCM Requires CUCM Version 10.5.2 or later with device pack for Room 55 Cisco Expressway Native registration wi
IPv6 network support Single call stack support for both H.323 and SIP Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ Support for both static and automatic IP configuration (stateles
Security features Management using HTTPS and SSH IP administration password Menu administration password Disable IP services Network settings protection
Certificate management Certificate Authority Proxy Function (CAPF) support for additional security Manufacturer-Installed Certificates (MIC) Locally Significant Certificates (LSC) X.509 Digital Certifica
Other interfaces USB 2.0 port type A, USB 2.0 port type B, mUSB, factory reset pinhole
Power Autosensing power supply 100-240 VAC, 1.8-0.8A, 50/60 Hz Rated: 142W maximum Power consumption: 142W at maximum standardized configuration Standby power consumption: 40W
Operating temperature and humidity 0°C to 40°C (32°F to 104°F) ambient temperature 10% to 90% Relative Humidity (RH)
Storage and transport temperature 20°C to 60°C (-4°F to 140°F) at RH 10% to 90% (noncondensing)
Physical dimensions (H x W x D) Cisco Webex Room 55 with: Floor stand: 62.7 x 49 x 30.5 in (1593 x 1245 x 774mm) Wall mount: 32.8 x 49.0 x 5.1 in (832 x 1245 x 130mm) Wheel base: 62.7 x 49.0 x 30.5 in (1651 x 124
Weight Cisco Webex Room 55 with (all weight without packaging): Floor stand: 83.8 lb (38kg) Wall mount: 68.3 lb (31kg) Wheel base: 85.1 lb (38.6kg) Main unit only: 66.1 lb (30kg)
Physical dimensions and weight of packag Cisco Webex Room 55 package size with: Floor stand: 42.5 x 54.3 x 17.3 in (1080 x 1380 x 440mm) Wall mount: 46.9 x 53.9 x 17.3 in (1190 x 1370 x 440mm) Wheel base: 42.5 x 54.3 x 17
Cisco Webex Room 55 shipping weight with Floor stand: 110 lb (50kg) Wall mount: 88 lb (40kg) Wheel base: 110 lb (50kg)
Camera overview 5K UltraHD camera Supports up to 60 fps (max 30 fps with speaker tracking and best overview enabled) 15.1 MP image sensor (5184 x 2916 pixels) 1/1.7 CMOS 3x zoom f/2.0 aperture 83°
Product type Network Accessories
Weight 1.01 kg
Warranty 12 months
