Features
Immersive Flight, Broaden Your Horizons
Pair it with DJI RC Motion 3 to get a fully immersive motion control experience, or use it with the RC-N2 or RC 2 remote controllers to pilot a 3-axis-gimbal camera drone. All this delivers silky-smooth live feeds so you can fully enjoy the FPV flying experience.
O4 Video Transmission, Compatible with Air 3 and Mini 4 Pro
With Avata 2, O4 video transmission delivers ultra-low latency at 24 ms and a high bitrate of 60Mbps. Also compatible with Air 3 and Mini 4 Pro, the reliable O4 HD transmission offers crystal-clear and fluid first-person views.
Real View PiP, Safety in Sight
Without removing your goggles, you can now conveniently observe your surroundings to get enhanced flight safety.
All-Around Comfort and Convenience
Dazzling Upgrades: Enjoy a 1080p Micro-OLED screen with a refresh rate of up to 100 Hz*, alongside the TüV Rheinland Low Blue Light Certification. Accommodates diopter adjustments from -6.0 D to +2.0 D for nearsighted and farsighted users.
Battery and Headband Integration: The lightweight, comfortable design that integrates the headband liberates you from tangled cables and offers a lengthy 3-hour operating time.**
One-Tap Defogging: With defogging enabled, you get a convenient solution for sudden changes in temperature or high-humidity conditions.
More Fun with Wireless Streaming
Stream your flight in real-time on the DJI Fly app of your smartphone via Wi-Fi connection.***
You can also import panoramic and 3D videos onto an SD card and play them back using Goggles 3 for an immersive experience that seems almost within reach.

* The screen refresh rate changes with the video transmission frame rate. It may switch between 100 Hz and 60 Hz to adapt to the current video transmission frame rate.
** The 3-hour max operating time was measured at an ambient temperature of 25° C (77° F), screen brightness at 4, connected to the DJI Avata 2 aircraft, video transmission set to 1080p/100fps, Head Tracking off, Real View off, and the goggles' battery fully charged and not supplying power to external devices such as smartphones.
*** Some countries and regions prohibit the use of the 5.1GHz or 5.8GHz frequency band, or both. In some countries and regions, the 5.1GHz frequency is only allowed for indoor use. If the 5.1GHz/5.8GHz frequency bands are not available (such as in Japan), screen sharing to the smartphone via Wi-Fi is not available. To achieve this function, a wired connection is recommended. Before flying, make sure to check and comply with local radio and aviation laws and regulations.
DJI Warranty Information
Manufacturer's warranty for DJI products may vary depending on the part under question, batteries have 3-6 months manufacturer's warranty while the remote control might have 12 months manufacturer's warranty. More information can be found on the DJI website.
Specifications
Technical Specifications
| Product Type | Goggles |
|---|---|
| Brand | DJI |
| MPN | CP-FP-00000159 |
| Compatibility | DJI Avata 2DJI Mini 4 ProDJI Air 3DJI NeoDJI O4 Air Unit ProDJI O4 Air UnitDJI O3 Air Unit |
| Model | TKGS3 |
| Weight | Approx. 470 g (battery included) |
| Dimensions (L×W×H) | With antennas folded: 170×109×112 mm (L×W×H)With antennas unfolded: 205×109×112 mm (L×W×H) |
| Screen Size (single screen) | 0.49 inch |
| Resolution (single screen) | 1920×1080 |
| Refresh Rate | Up to 100 Hz |
| Interpupillary Distance Range | 56-72 mm |
| Diopter Adjustment Range | -6.0 D to +2.0 D |
| FOV (single screen) | 44° |
| Video Recording Format | MOV |
| Supported Video and Audio Playback Formats | MP4, MOV (video coding formats: H.264, H.265; audio formats: AAC, PCM)Panoramic Video: Spherical 2D panoramic videos.3D Video: Half-Side-by-Side (HSBS), Full-Side-by-Side (FSBS), Half Over-Under (HOU), Full Over-Under (FOU).Max Video Specification: 4K/60fps |
| Real View FOV | 44° |
| Operating Temperature | -10°C to 40°C (14°F to 104°F) |
| Power Input | Built-in battery |
| Supported SD Cards | microSD (up to 512 GB) |
| Recommended microSD Cards | Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXCKingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXCKingston CANVAS Go! Plus 256GB U3 A2 V30 microSDXCKingston CANVAS Go! Plus 512GB U3 A2 V30 microSDXCLexar Professional 1066x 64GB U3 A2 V30 microSDXCLexar Professional 1066x 128GB U3 A2 V30 microSDXCLexar Professional 1066x 256GB U3 A2 V30 microSDXCLexar Professional 1066x 512GB U3 A2 V30 microSDX |
| Video Transmission | When used with different aircraft, the goggles will automatically select the corresponding firmware to match the video transmission specification of the aircraft.With DJI Avata 2: DJI O4 |
| Operating Frequency | 2.4000-2.4835 GHz5.150-5.250 GHz5.725-5.850 GHzSome countries and regions prohibit the use of the 5.1GHz or 5.8GHz frequency band, or both. In some countries and regions, the 5.1GHz frequency is only allowed for indoor use. Before flying, make sure to check and comply with local regulations. |
| Transmitter Power (EIRP) | 2.4 GHz:< 33 dBm (FCC)< 20 dBm (CE/SRRC/MIC)5.1 GHz:< 23 dBm (CE)5.8 GHz:< 33 dBm (FCC)< 30 dBm (SRRC)< 14 dBm (CE) |
| Latency | With DJI Avata 2:1080p/100fps video transmission quality: latency down to 24 ms?1080p/60fps video transmission quality: latency down to 40 msMeasured in an open outdoor environment without interference. Actual data varies with different aircraft models. |
| Max Transmission Distance | When used with DJI Avata 2, DJI Goggles 3 can achieve the following max video transmission distance: 13 km (FCC); 10 km (CE/SRRC/MIC) |
| Max Video Bitrate | 60 MbpsMeasured in an outdoor open environment without interference. Actual data varies with the operating environment. |
| Protocol | Bluetooth 5.0 |
| Operating Frequency | 2.400-2.4835 GHz |
| Transmitter Power (EIRP) | < 10 dBm |
| Operating Frequency | 2.4000-2.4835 GHz |
| Transmitter Power (EIRP) | < 26 dBm (FCC)< 20 dBm (CE/SRRC/MIC) |
| Dimensions | 121×65×52.5 mm (L×W×H) |
| Capacity | 3000 mAh |
| Voltage | 5.6-8.4 V |
| Category | Li-ion |
| Chemical System | LiNiMnCoO2 |
| Energy | 21.6 Wh |
| Charging Temperature | 0° C to 50° C (32° F to 122° F) |
| Max Charging Power | 20 W (charging when powered off) |
| Runtime | Approx. 3 hoursThe 3-hour max operating time was measured at an ambient temperature of 25° C (77° F), screen brightness at 4, connected to the DJI Avata 2 aircraft, video transmission set to 1080p/100fps, Head Tracking off, Real View off, and the battery of the goggles fully charged and not supplying power to external devices such as smartphones. |
