Dynamix RPSK-16A8 8 Port 16A kWh Switched PDU Total Remote Power Monitoring & Outlet Control. Output 8x10A IEC C13 , Input 1x16A IEC C20 Socket 3M C19 to C20 power cord included.
Features
DYNAMIX 8 Port 16A kWh Switched PDU . Total Remote Power Monitoring & Outlet Control. Output 8x 10A IEC C13 , Input 1x 16A IEC C20 Socket to C20 power cord included.
kWh PDU provides advanced remote management features and power information including voltage, current, frequency, power factor, VA and kWh.
- Metre - true RMS current metre, voltage, frequency, power factor, active power, apparent power, total kWh, sub-total kWh
- Power monitor - total power monitoring by metre, web, SNMP, free bundle software
- Protocols - Http, Https, SNMP, DHCP, UDP
- Outlet control - individual, group, schedule, auto ping
- Power delay - power on/off sequence can be defined
- Alarm thresholds - User-defined alarm thresholds for warning and overload
- Event alert - total power monitoring by metre, web, SNMP
- Temp./humidity - optional (RPSK-ENV1)
- 3M input power cord included
Specifications
Technical Specifications
| Output | (8) IEC 320 C13 |
|---|---|
| Input | (1) IEC320 C20 Inlet; IEC320 C19 to C20 Power Cord 3M |
| Protection | (1) 16 AMP Circuit Breaker |
| SSL Indication | (1) Yellow LED |
| DHCP Indication | (1) Green LED |
| Output Status | (8) Green LED |
| Circuit Status | (1) Red LED |
| Network | (1) RJ45 for Ethernet |
| Temp./Humidity | (1) RJ11 for ENV probe connection |
| PDU ID | 1 Digits Seven Segments for PDU Identification |
| Meter | 3 Digits Seven Segments |
| Nominal Voltage | 230V |
| Voltage | 200V~ 240V full range |
| Frequency | 50/60HZ full range |
| Max. Output Current | 16 Amp |
| Temperature | 0 ~ 40 Celsius degree |
| Humidity | 0% ~ 90% |
| Size | 125 x 432 x 44 mm |
| Weight | 3.5 kg |
| REGULATORY APPROVALS | CE, EN 55022 Class A, EN 55024,EN 61000-3-2,EN 61000-3-3FCC Part 15 Class A, ICES-003 |
| Brand | Dynamix |
|---|---|
| Product Type | Power & Lighting |
