ALOGIC EL2DPHD4K-02 - ELMNTSDISPPRTTOHDMICBLW4KSPPRTMLE2MLE-2M
Features
Product Friendly Description
Designed for when performance, reliability and value count, Elements series cables are budget friendly while providing professional performance for home or commercial use.
These cables connect DisplayPort sources to HDMI displays and support HDMI resolutions up to the HDMI 2.0 maximum of 4K at 60Hz.
Engineered with low profile connectors and high flexibility, low bend radius cable, these cables are ideal for use where space is limited such as behind displays and in equipment racks.
Premium Performance
Most DisplayPort to HDMI cables are passive and rely on the DisplayPort source to be able to communicate properly with the HDMI display. Unfortunately this leads to compatibility issues with some equipment and it also places limits on the performance of the connection.
ALOGIC Elements series active 4K cables feature active protocol conversion to ensure compatibility between devices and support double the frame rate of passive cables for silky smooth, lag free video.
Being able to provide high frame rates on supported monitors makes sure you get the smoothest video possible and gets the most out of gaming.
Reliability You Can Count On
Engineered with professional applications in mind, these cables utilise highly flexible 30AWG cable for reliable performance and ease of installation in home or business uses.
Alogic's robust ABS low-profile DisplayPort connectors provide a comfortable grip and easy insertion while standing up to use in high-traffic environments. The connectors are latching, ensuring they remain securely connected.
With hundreds of thousands of Alogic cables installed in professional environments, this range draws upon Alogic's extensive experience in providing products that withstand the test of time in the most demanding applications.
Whether at home or in the office, you can be assured that these cables won't let you down.
Specifications
Technical Specifications
| MPN | EL2DPHD4K-02 |
|---|---|
| Input / Output | Input: DisplayPort Male, Output: HDMI Type A Male (uni-directional) |
| Video Support | Compliant with HDMI 2.0b, HDCP 1.4/2.2Supports 3D video |
| Resolution | - Refresh rates to 240Hz at 1080p- Colour depths to 16 bit per colour |
| HDMI Features | Supports the following HDMI features (when used with equipment that implement these features):- Extended Consumer Electronics Control (CEC)- Adaptive sync; G-Sync and Freesync compatible- High Dynamic Range (HDR) video support including HDR10,Dolby Vision, HLG- Multiple audio stream and Dual View video support |
| Data Rate | HDMI 2.0, 18Gbps, Premium High Speed class cable (Backwards compatible with all previous HDMI standards) |
| Compatibility | Use for connecting DisplayPort source devices to HDMI displays. Canbe used with any DisplayPort source device (including outputs that do not support DP++).This cable is uni-directional; it cannot be used to connect a HDMI source to a DisplayPort display. |
| Materials | ABS DP Connector, PVC Jacket and HDMI Connector |
| Colour | Dark Grey |
| Length | 2m |
| Compliance | RoHS |
| Brand | ALOGIC |
|---|---|
| Product Type | PC Peripherals > Cables > DisplayPort Cables |
| Weight | 0.059 kg |
| Warranty |
|---|
Note:
Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
