ELO E318746 TOUCH MONITORS ELO ELO D/TOP 1502L Z-BEZEL INTELLI VGA/HDMI USB BLK

SKU: E318746 ● In Stock
$1,401.74
inc GST ▲ +GST
Free shipping over $299 Genuine product 7-day returns

You May Also Like

Features

ELO E318746 TOUCH MONITORS ELO ELO D/TOP 1502L Z-BEZEL INTELLI VGA/HDMI USB BLK

Specifications

Technical Specifications

Manufacturer part number E318746
Model 1502L
Color Black
Active display area Horizontal: 10.06" (345.2mm); Vertical 7.66" (194.6mm)
Monitor dimensions Width: 15.24" (387mm); Height: 9.62" (244.4mm); Depth: 1.29" (32.9mm)
LCD technology Active matrix TFT LCD with LED backlighting
Diagonal Size 15.6"
Aspect ratio 16:9
Number of touches 10 touch points
Native (Optimal) Resolution Full HD model: 1920 x 1080; HD (WXGA) model: 1366 x 768
Other Supported Resolutions Full HD model: 640x480 60Hz; 720x576 50Hz; 800x600 56, 60Hz; 1024x768 60Hz; 1280x720 50, 60Hz; 1280x800 at 60, 60RB Hz; 1280x960 60Hz; 1280x1024 60Hz; 1360x768 at 60Hz; 1366x768 60
Colors 262,000
Brightness (typical) Full HD model: LCD Panel: 300 nits; with IntelliTouch Pro PCAP: 270 nits HD model: LCD Panel: 220 nits; with IntelliTouch Pro PCAP: 187 nits
Response Time - Total (typical) Full HD model: 35 ms; HD model: 10 ms
Viewing Angle (typical) Full HD model: Horizontal: +/-80° or 160° total; Vertical: +/-80° or 160 ° total HD model: Horizontal: 90° total; Vertical: 65 ° total
Contrast Ratio (typical) Full HD model: 700:1; HD model: 600:1
Video Mini-VGA (Mini-VGA to VGA DE-15 Male connecter cable included); HDMI (HDMI cable included) Input Video Horizontal Sync frequency range: 31.5 - 60KHz Input Video Vertical Sync (fram
Power Monitor input power connector: Coaxial power jack (2.5 mm pin outer diameter, 6.4mm barrel inner diameter); Monitor input power signal specifications: 12VDC +/- 5%; Adapter input v
Speakers 2 x 2W internal speakers
Weight Unpackaged with stand: 6.72 lbs / 3.05 kg; Unpackaged without stand: 6.64 lbs / 3.0 kg Packaged: 11.2 lbs / 5.08 kg
Shipping box dimensions (W x D x H) 18" (457mm) x 13.7" (347mm) x 7.13" (181mm)
On-Screen Display (OSD) Accessible through switches along the bottom. Controls: Menu, Power, Up, Down, Select Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Rati
Mounting Options VESA 4-hole 75mm and 100mm mounting interface on rear of unit Optional tabletop stand available for purchase (P/N E044162)
Temperature Operating: 0 °C to 40 °C /32 °F to 104 °F; Storage: -20 °C to 60 °C /-4 °F to 140 °F
Humidity (non-condensing) Operating: 20%-80%; Storage: 10%-95%
Regulatory approvals and declarations Canada cUL, IC; Europe CE; Japan VCCI; United States UL, FCC
MTBF 50,000 hours demonstrated
Product type POS / Scanning
Weight 1.01 kg
Warranty 12 months
