Enlogic ENL-EA9119 Serial Communication Cable RJ-45 to DB-9
Enlogic

Enlogic ENL-EA9119 Serial Communication Cable RJ-45 to DB-9

SKU: ENL-EA9119 ● In Stock
$55.68
inc GST ▲ +GST
Free shipping over $299 Genuine product 7-day returns

You May Also Like

Features

Enlogic ENL-EA9119 Serial Communication Cable

The Enlogic EN Series PDU and EZ Series Inline Energy Meter provide a command line interface (CLI) that enables data center administrators to perform basic management tasks. Enlogic's Serial Communication Cable (RJ45-DB9) is used to establish a serial connection between a computer and any Enlogic EN Series PDU or EZ Series Inline Energy Meter.

Installation Instructions

1. Connect the RJ45 end of the Serial Communication Cable into the Serial+RS485-1 port on the EN Series PDU or EZ Inline Energy Meter.

2. Connect the DB9 end of the cable into the serial port (COM) on a computer.
Note: A DB9 serial to USB connection cable may be required, depending on hardware configuration.

3. Use the connected computer to open a communications program such as HyperTerminal or PuTTY.

4. Select the appropriate COM port and confirm the port settings are as follows:

- Bits per second: 115200
- Data bits: 8
- Stop bits: 1
- Parity: None
- Flow control: None

The Enlogic EN Series PDU or EZ Series Inline Energy Meter is connected and ready for communication.

Specifications

Technical Specifications

Product Type Serial Communication Cable
Brand Enlogic
Operating Temperature -5 to 60°C (23 to 140°F)
Storage Temperature -20 to 60°C (-4 to 140°F)
Humidity (Operating/Storage) 5-90% RH / 5-95% RH; non-condensing
Max Operating Elevation 3,000 m (9,840 ft)
Safety Verification ROHS, REACH
