GP-P650SS - Gigabyte GP-P650SS 650W ATX Silver PSU 3yr wty

Gigabyte

GP-P650SS - Gigabyte GP-P650SS 650W ATX Silver PSU 3yr wty

SKU: GP-P650SS ● In Stock

$97.75

Free shipping over $299 Genuine product 7-day returns

GP-P650SS - Gigabyte GP-P650SS 650W ATX Silver PSU 3yr wty

Overview

80 PLUS
SILVER CERTIFIED
The 80 Plus Silver certification (230V EU) guarantees a 90% efficiency rate at a 50% load, resulting in reduced power wastage, diminished heat generation, and minimized fan noise.

Support Intel
ATX 3.0 standard
The P650SS can sustain up to 2x total power excursion. It is fully compatible with Intel PSDG (Power Supply Design Guide) ATX 3.0 standard which supports up to 200% power excursion, reaches 70% low load efficiency and complies with required power supply timing standards.

120MM FLUID DYNAMIC
BEARING(FDB) FAN
High-performance Fluid Dynamic Bearing fan uses oil film shock absorption technology to effectively reduce noise, making it quieter than conventional sleeve fan and providing more than twice the lifespan. In addition, the fan will detect the current power usage and temperature, automatically adjust the fan speed to minimize the noise.

RELIABLE FLAT CABLE DESIGN
The utilization of flat cables minimizes clutter while enhancing the thermal performance of the chassis.

SINGLE +12V RAIL
The single +12V rail delivers optimal power output, stability, and hardware compatibility. This design not only simplifies power cable installation but also stands as the most effective choice for overclocking purposes.

PROTECTION
To guarantee the stable operation of your entire computer system under any circumstances, we have incorporated a range of protective features including OCP, OTP, OVP, OPP, UVP, and SCP. Moreover, we have obtained safety certifications from various countries to ensure the consistent and secure functioning of your system.

80 PLUS Silver certified (230V EU)
Support Intel ATX 3.0 standard
120mm Fluid Dynamic Bearing (FDB) Fan
Flat cable design
Powerful single +12V rail
OVP/OPP/SCP/UVP/OCP/OTP protection

Technical Specifications

Total power	650
AC input voltage	155-240
Input current	6.3
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	100
Combined power (+12V)	649.2
Combined power (+5V)	100
Combined power (-12V)	3.6
Combined power (+5Vsb)	15
Max output current (+3.3V)	20
Max output current (+12V)	54.1
Max output current (+5V)	20
Max output current (-12V)	0.3
Max output current (+5Vsb)	3
Power protection features	Over power,Overcharge,Short circuit,Under voltage
Motherboard power connector	20+4 pin ATX
Motherboard power cable length	600
Number of SATA power connectors	5
SATA power cable length	120,500
Peripheral (Molex) power connectors (4-pin)	2
Peripheral (Molex) power cable length	120,500
PCI Express power connectors (6+2 pin)	4
PCI Express power cable length	650
CPU P4 connector (4-pin)	1
CPU power connector (4+4 pin)	Y
CPU power cable length	600
ATX power connector (20+4 pin)	Y
Floppy disk drive connector	Y
Cabling type	Non-Modular
80 PLUS certification	80 PLUS Bronze
Purpose	PC
Power supply unit (PSU) form factor	ATX
ATX version	3.0
Bearing technology	HDB
Mean time between failures (MTBF)	100000
Product colour	Black
Cooling type	Active
Fan diameter	120
Number of fans	1
Fan location	Top
On/off switch	Y
Width	150
Depth	140
Height	86
Package type	Box
Harmonized System (HS) code	84733020
Noise level (silent mode, <30%)	20
Noise level (quiet mode, 50%)	29
Noise level (full-load mode, 100%)	39
Power management	Y
