Grandstream GWN7660EM Wi-Fi 6 Pluggable Mesh Access Point

Description

Specifications

Resources

Package Contents

The Grandstream GWN7660EM is an AX3000 Wi-Fi 6 access point with a socket design, enabling simple deployment and superior performance. It can be used as a wireless extender, which works with the GWN7062E/ET and will work with future Grandstream routers to quickly build a home wireless mesh networking to expand network coverage. It offers 2x2:2 MU-MIMO technology on the 2.4G band and 3x3:2 MU-MIMO on the 5G band as well as a sophisticated antenna design and uses XTRA Range technology with beamforming for maximum network throughput and expanded Wi-Fi coverage range. To ensure easy installation and management, the GWN7660EM uses a controller-less distributed network management design in which the controller is embedded within the product’s Web user interface. The GWN7660EM is also supported by GDMS Networking and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. It is a suitable Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for advanced QoS, low-latency real- time applications, mesh networks, captive portals, 128 concurrent clients per AP and 1 x 1 Gigabit network port, GWN7660EM is an ideal Wi-Fi access point for small and medium household users to achieve high-speed Wi-Fi coverage in the whole house.

Details
Manufacturer Code	GWN7660EM
Antenna	1 single frequency antenna and 2 dual frequency antennas; 2.4GHz x 2, maximum gain 2.5 dBi; 5GHz x 3, maximum gain 2.5 dBi
MIMO	2.4GHz: 2x2:2, MU-MIMO; 5GHz: 3x3:2, MU-MIMO
Frequency Bands	2.4GHz Radio: 2400 - 2483.5 MHz; 5GHz Radio: 5150 - 5895 MHz; *Not all frequency bands can be used in all regions
Channel Bandwidth	2.4G: 20 and 40 MHz; 5G: 20, 40, 80 and 160 MHz
Wi-Fi Standards	IEEE 802.11a/b/g/n/ac/ax
SSIDs	16 SSIDs total, 8 per radio (2.4GHz & 5GHz)
Mesh	2.4G, 2.4G & 5G, 5G; Support mesh with GWN7062E series by SYNC key; Support mesh with GWN7600 series
Maximum Tx Power	2.4G: 26 dBm; 5G: 24 dBm; *Maximum power varies by country, frequency band and MCS rate
Coverage Range	Up to 120 meters (Coverage range can vary based on environment)
Network Ports	1x autosensing 10/100/1000 Base-T Ethernet Port
LEDs	1 tri-color LED for device tracking and status indication
Auxiliary Ports	1x Reset Pinhole, 1x SYNC Key
Maximum Power Consumption	12W
Dimensions	Unit: 110 × 110 × 56.7 mm
