J5create

J5create HDMI to VGA Display Adapter with Audio, Easily Transform HDMI Device into a VGA connection With Audio, Reserved Micro USB B Type Power Input Port

SKU: JDA213S ● In Stock
$32.89
Free shipping over $299 Genuine product 7-day returns

Features

- Easy-to-use cable
- No software required
- No power adapter required
- Easily make your new HDMI equipment compatible with a VGA display
- Supports PC resolutions up to 1920x1200 @ 60Hz (WUXGA) and HDTV resolutions up to 1080p @ 60Hz
- 2-channel analogue audio output
- Reserved Micro USB B Type power input port, if the lack of HDMI output device can be powered separately
- HDMI Receiver compliant with HDMI 1.4 specification
- VGA output is compliant with VESA VSIS v1r2 specification

The JDA213 HDMI to VGA adapter allows you to connect the HDMI output from your laptop, Ultrabook, desktop, tablet, blue-ray, DVD player, digital set-top box, digital camera, video camera, or gaming console equipment to the VGA input of a monitor or projector by converting the HDMI video signal from the output device into a VGA output and separate 2-channel analog audio. The adapter supports resolutions including high definition 1080p, up to 1920x1200, which eliminates the expense of upgrading a VGA display for the sake of compatibility. The adapter can also increase your productivity by extending your computer's desktop onto a secondary monitor, doubling available workspace. This adapter has a high quality, compact design for long-term durability and a minimal footprint.Once you've experienced multiple monitors, you'll never want to go back to a single monitor again.

Multiple Monitors for the Multitasking Professional

Supports FHD (1080p) Video Resolutions

Allows you to quickly and easily connect your Mac® or PC to an external monitor, HDTV, projector or other display device.(ALL) DisplayPort™ V1.1a required on graphics card or video source to support 1920 x 1200 @ 60 Hz resolution.

Reserved Micro-B power Input

Connect optional power adapter for power hungry devices via micro-B port to ensure maximum performance if you are using a high-powered device.

Active DisplayPort™ Conversion

Active high data rate adapter with clock & data recovery chip built-in. Provides resolutions up to 4K, transmitting HD video and high quality sound.

Increase Efficiency

The easiest way to add a second display.

Universal Compatibility

Compatible with both Mac® & Windows®. VGA output is compliant with VESA VSIS vlr2 specification.

Small, Compact, and Lightweight

Pocket-sized, easily take it with you to work, while traveling, on business trips, etc.

Specifications

Technical Specifications

VGA Output VGA (15 pin; High Density D-Sub) Female
Audio Output 3.5 mm Mini-Jack Female
HDMI™ Input HDMI™ (19 pin) Male
Power USB™ Micro-B (5 pin) Female 5V
Converter Type Format Converter
Audio Yes
Maximum Analog Resolutions 1920 x 1200
Wide Screen Supported Yes
Audio Specifications 2-Channel Stereo
Housing Material Plastic
Dimensions Main Body:1.6 (W) x 1.8 (H) x 0.6 (D) in.40 (W) x 45 (H) x 14 (D) mmCable length: 4 in. / 100 mm
Weight Approximately 54g
Device: HDMI™ devices including, but not limited to:- Desktop, Laptop, Ultrabook™ (PC and Mac®)- DVD players and Blu-ray™ players- Smart TV Box- Digital camera- Gaming consoles (PS3™ and Xbox™)
VGA display devices including, but not limited to: - Projector- Display monitor- TV
Audio devices including, but not limited to: -Amplifier speaker- Home Theater
Package Contents JDA213S HDMI™ to VGA adapterQuick Installation Guide
