JBL PROFESSIONAL

JBL PROFESSIONAL CSM-14 - 4CH 1 ZONE COMMERCIAL RACK MIXER

SKU: CSM-14 ● In Stock
$1,040.62
Free shipping over $299 Genuine product 7-day returns

JBL PROFESSIONAL CSM-14 - 4CH 1 ZONE COMMERCIAL RACK MIXER

Features

Commercial Rack Mixer with 4 inputs and 1 output. Fanless 1U design, independent bass/treble controls, GreenEdge energy-efficiency, priority muting, VOX ducking and phantom power on all models. Optional JBL CSR-V wall controller via Ethernet cable.

The JBL® Commercial Series Mixers (CSM) deliver unsurpassed quality in commercial sound.

Easily configured for a range of applications, such as background music, security and paging, CSM units are designed for everything from schools and hospitals to restaurants and fitness facilities.

They feature RJ45 connectors for use with JBLCSR-V in-wall volume controls, and a universal power supply that accepts AC voltages from 100 to 240 VAC, 50/60 Hz. Plus, they're built using HARMAN's GreenEdge™ clean standards to offer numerous energy-efficient benefits, including a lighter weight, space-saving design, and conforming to RoHS standards.

- 4 inputs with 1 channel output
- Fanless, space-saving 1U design
- Independent bass/treble controls
- Euro-block type mic/line input and output connectors, and unbalanced RCA inputs for consumer connection
- Supports JBL CSR-V wall controller via Ethernet cable
- Priority muting, VOX ducking, and phantom power for all models
- Includes a rack mounting kit for installations to a cabinet

Specifications

Technical Specifications

Manufacturer Part Number CSM-14
Inputs 4
Output Channels 1
Input Sensitivity (Mic) 3mVrms
Input Sensitivity (Line) 775mVrms
Input Sensitivity (RCA) 300mVrms
Phantom Power 27VDC
Priority Muting Yes
Configurable Output Routing No
AC Line Voltage 100 - 240V, 50/60 Hz
Dimensions 1.7" x 8.6" x 11.9" (43.3mm x 218.5 mm x 303.4mm)
