LevelOne
LevelOne OAN-4121 - 5GHz Omni-directional 12dBi Outdoor Antenna with mounting kit (Promotional Price)
$115.00
Free shipping over $299
Genuine product
7-day returns
LevelOne OAN-4121 - 5GHz Omni-directional 12dBi Outdoor Antenna with mounting kit (Promotional Price)
Overview
The LevelOne OAN-4121 is an omni-directional antenna operating on the 5 GHz frequency that can be mounted either indoors or outdoors. The antenna’s gain value is 12dBi, and if mounted outdoors the weatherproof housing can withstand temperatures from minus 30°C up to 60°C, as well as rain, snow, dust and other harsh conditions.
- For IEEE 802.11a/n Wireless applications in 5 GHz frequency range
- Provides 12dBi omnidirectional operation
- Low wind loading
- 40°C to 70°C operating temperature range
Technical Specifications
| Frequency band | 5.45 ~ 5.835 |
|---|---|
| Networking standards | IEEE 802.11a,IEEE 802.11n |
| Impedance | 50 |
| Horizontal beam width | 360 |
| Vertical beam width | 17.5 |
| Antenna gain level (max) | 12 |
| Antenna type | Omni-directional antenna |
| Antenna connector type | N-type |
| Polarization | Vertical polarization |
| Voltage Standing Wave Ratio (VSWR) | 2.0 |
| Product colour | White |
| Protection features | Dust resistant,Snow resistant,Water resistant |
| Survival wind speed | 180 |
| Mounting | Pole |
| Purpose | Indoor & outdoor |
| Maximum cable loss with connectors | -10 |
| Operating temperature (T-T) | -30 - 60 |
| Operating relative humidity (H-H) | 0 - 95 |
| Width | 70 |
| Depth | 558.5 |
| Height | 53 |
| Weight | 300 |
| Package width | 83 |
| Package depth | 650 |
| Package height | 72 |
| Package weight | 504 |
| Package type | Box |
| Mounting kit | Y |
| Quick installation guide | Y |
| Harmonized System (HS) code | 85177100 |
| Country of origin | Taiwan |
| Master (outer) case width | 385 |
| Master (outer) case length | 205 |
| Master (outer) case height | 670 |
| Master (outer) case gross weight | 6000 |
| Products per master (outer) case | 10 |
