LGD-033154 - Legrand Keystone RJ45 Socket LCS3 - Cat6A STP
You May Also Like
IPL-UTP6-GY-0.5 - 0.5 Metre Cat6 UTP Indoor Ethernet Cable - Grey
IPL-UTP6-GY-0.3 - 0.3 Metre Cat6 UTP Indoor Ethernet Cable - Grey
Features
LCS² - Keystone RJ 45 socket category 6 STP fast crimping connection
RJ45 connector equipped with a rotating locking system. Suitable for category 6 U/UTP AWG 22 single-core cables up to AWG 26 and AWG multicore cables. It enables high speed data transmission.
- Category 6A STP : Data rate up to 10 GigaBit/s. This allows you to download a 1 GigaBytes file in 1 second.
- With fast crimping connection
- Accepts the following cable connectors : RJ11 (4 contacts), RJ12 (6 contacts), RJ45 (9 contacts).
Recommendation / Restriction
Max. number of connections and disconnections: 5 without refreshing the cable. Conform to standards ISO/IEC 11801 Ed. 3.0, EN 50173-1 and TIA/EIA 568 C
Installation
The RJ45 connectors are equipped with a rotating locking system that does not require special tools and enables rewiring in the event of error. Can be integrated in several supports : Axolute, Living Light, Light Tech, Matix.
Usage
High reliability : 2500 movements (plug insertion/withdrawal)
Specifications
Technical Specifications
| Type of connector | RJ45 8(8) |
|---|---|
| Screened | Yes |
| Category | 6A (TIA) |
| Connection type | Other |
| Special tool necessary | No |
| Suitable for round cable | Yes |
| Suitable for flat cable | No |
| Suitable for solid conductors | Yes |
| Colour | Colourless |
| AWG-range | 22-26 |
| Width | 19.1 mm |
| Height | 29 mm |
| Depth | 37 mm |
| Terminal marking indication | Yes |
| Antimicrobial treatment | No |
| Brand | Legrand |
|---|---|
| Product Type | Networking > Network Cables |
| Weight | 0.5 kg |
| Warranty |
|---|
