LH13QBCTBGBXXY - SAMSUNG (QBC-T) INTERACTIVE SIGNAGE, 13" FHD TOUCH, 500NITS, HDMI, LAN/WIFI, 16H/7D, 3YR
LH13QBCTBGBXXY - SAMSUNG (QBC-T) INTERACTIVE SIGNAGE, 13" FHD TOUCH, 500NITS, HDMI, LAN/WIFI, 16H/7D, 3YR
Overview
Effective display for compact places
Designed to bring visibility to the most limited spaces, the 13-inch QB13C-T combines a space-efficient form with intuitive touch capability. Its responsive 10-point capacitive panel helps enable interaction, making it suitable for customer-facing displays, wayfinding, and compact digital signage. Slim, stylish, and versatile—it fits where communication matters.
Interactive Touch Panel
Built for compact business spaces, the QB13C-T combines responsive multi-touch with a slim design. Its intuitive touch function helps make it easy to navigate menus, showcase products, and deliver interactive content. With support for up to 10 touch points, it’s suitable for environments where engaging, interactive experiences are needed in limited space.
Compact 13" Size & Slim Design
With a small and slim design, the 13-inch compact display fits in tight spaces, perfect for helping to maximise visibility without hindering performance. Its small design is packed with business-ready functionality, making it a smart choice for small spaces.
Home UI
The Home UI brings commonly used settings and sources together in a single, easy-to-access screen. Whether there is a need to adjust display inputs or managing device settings, users can navigate key tools fast—without digging through multiple menus.
Dual Wi-Fi (2.4GHz + 5GHz)
QB13C-T supports dual-band Wi-Fi with both 2.4GHz and 5GHz frequencies, enabling fast network connections and high data transmission speeds—especially in high-traffic areas.
SmartThings Pro*
SmartThings Pro* brings connectivity into Samsung signage, helping enable seamless integration with other smart devices across business environments. From lighting and appliances to building systems, signage becomes part of a connected ecosystem—controlled, monitored, and automated through a single platform.
Samsung VXT*
The cloud-based Samsung VXT* brings content management and remote device management capabilities. Remotely manage hardware settings and troubleshoot issues while creating and deploying content.
- Compact 13" Size & Slim Design
- Interactive Touch Panel
- Home UI
Technical Specifications
| Panel type | ADS |
|---|---|
| Display diagonal | 13 |
| Display technology | LCD |
| Display resolution | 1920 x 1080 |
| Display brightness | 500 |
| HD type | Full HD |
| Touchscreen | Y |
| Touchscreen technology | Capacitive |
| Response time | 30 |
| Contrast ratio (typical) | 600:1 |
| Contrast ratio (dynamic) | 10000:1 |
| Viewing angle, horizontal | 170 |
| Viewing angle, vertical | 170 |
| Pixel pitch | 0.153 x 0.153 |
| Display diagonal (metric) | 33 |
| Horizontal scan range | 30 - 81 |
| Vertical scan range | 48 - 75 |
| Haze rate | 25 |
| Pixel frequency (max) | 148.5 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DVI port | N |
| USB port | Y |
| USB ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 interface | Y |
| Built-in speaker(s) | N |
| Product design | Interactive flat panel |
| Placement supported | Indoor |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 100 x 100 |
| Purpose | Retail |
| TV tuner integrated | N |
| Operating hours (hours/days) | 16/7 |
| HDCP | Y |
| HDCP version | 2.2 |
| Power consumption (standby) | 0.5 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Internal storage capacity | 8 |
| Operating system installed | Tizen 7.0 |
| Display width | 322 |
| Display depth | 22 |
| Display height | 193.5 |
| Display weight | 1100 |
| Package width | 520 |
| Package depth | 238 |
| Package height | 64 |
| Package weight | 2000 |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 10 - 80 |
| Ethernet LAN | Y |
| Wi-Fi | Y |
| Compliance certificates | Electromagnetic Compatibility (EMC) |
| Audio output | 1 |
| Bluetooth | Y |
| RS-232 input ports | 1 |
