Lockly Guard Athena Swing Edition (228SW) 1-3/8"
Features
LOCKLY GUARD™ ATHENA SWING EDITION
Access for thin framed swing-style doors
Provides main entrance lever access and security for thin framed metal, aluminum or wooden swinging doors.
- Hack-proof PIN Genie® digital touchscreen
- 3D biometric fingerprint sensor access - Stores up to 99 fingerprints
- IPX4 rated for water protection
- Issue Offline Access Codes™ that do not require users to download an app or have WiFi or Internet connection to use
- Fast Pass MIFARE RFID access
- eKeys - Grant one-time use or specific time duration access by issuing codes or digital eKeys via a mobile access
- Grant access, even when you're not home - Remotely lock and unlock your door from anywhere using the Lockly app
- Works with Lockly app & Lockly\OS ™
Note: This product is model number PGD228WSWSS-28
Specifications
Technical Specifications
| Function | Narrow Stile Mortise Smart lock |
|---|---|
| Dimensions (HxW) | 12 5/16" x 1 5/8" (313mm x 42mm) |
| Fit | doorframes 2" - 3" (50.8mm - 76.2mm) |
| Door handle | field reversible for L/R swing doors |
| Backset | 1 1/2" (28mm) |
| Latch | 1/2" (12.7mm) steel |
| Doorframe thickness | 1" - 2 1/8" (25.4mm - 54mm) |
| Doorframe width | 2" -3" (50.8mm - 76.2mm) |
| Working environment | -5 ~170°F(-20 ~ 76°C) |
| Power Supply | AA x 4 |
| Colors | Stainless Steel |
| Included | Lockly Guard Swing Edition smart lockMortise AssemblySecure Link Wifi hubWired Door SensorMIFARE RFID Cards x 3Laser Cut Keys x 5Installation ScrewsStrike PlateStrike Plate HousingBack PlateAA Alkaline Batteries x 4Quick Start GuideInstallation and User Manuals |
| Brand | Lockly |
|---|---|
| Product Type | Smart Home & Security > Smart Locks |
| Weight | 0.5 kg |
