MikroTik D53G-5HacD2HnD-TC-R11e-LTE7
MikroTik D53G-5HacD2HnD-TC-R11e-LTE7
MikroTik

MikroTik Chateau LTE7 Cat7, 3G/4G/LTE Gigabit Cellular and Wi-Fi Router

SKU: D53G-5HacD2HnD-TC-R11e-LTE7 ● In Stock
$221.74
inc GST ▲ +GST
Free shipping over $299 Genuine product 7-day returns

You May Also Like

Features

MikroTik Chateau LTE7 Cat7, 3G/4G/LTE Gigabit Cellular and Wi-Fi Router

Specifications

Technical Specifications

Manufacturer part number D53G-5HacD2HnD-TC-R11e-LTE7
MPN D53G-5HacD2HnD-TC&R11e-LTE7
Architecture ARM 32bit
CPU IPQ-4019
CPU core count 4
CPU nominal frequency 448-896 (auto) MHz
CPU Threads count 4
Switch chip model IPQ-4019
RouterOS license 4
Operating System RouterOS v7
Size of RAM 256 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 200'000 hours at 25°C
Tested ambient temperature 40°C to 70°C
Number of DC inputs 1 (DC jack)
DC jack input Voltage 12-28 V
Max power consumption 20 W
Max power consumption without attachment 14.1 W
Cooling type Passive
3G Category R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
3G bands 1 (2100 MHz) 5 (850 MHz) 8 (900 MHz) 3 (1800 MHz)
LTE Category 7 (DL: 300 Mbps; UL: 100 Mbps)
MIMO DL 2x2
MIMO UL 1x1
LTE FDD bands 1 (2100 MHz) 3 (1800 MHz) 5 (850 MHz) 7 (2600 MHz) 8 (900 MHz) 20 (800 MHz) 28 (700 MHz)
LTE TDD bands 38 (2600 MHz) 40 (2300 MHz) 41 (2500 MHz)
TAC 35312597
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz Number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 2
Wireless 2.4 GHz chip model IPQ-4019
Wireless 2.4 GHz generation Wi-Fi 4
Wireless 5 GHz Max data rate 867 Mbit/s
Wireless 5 GHz Number of chains 2
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 4
Wireless 5 GHz chip model IPQ-4019
Wireless 5 GHz generation Wi-Fi 5
10/100/1000 Ethernet ports 5
Number of SIM slots 1 Modem (Micro SIM)
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1
Mode button Yes
Certification CE, EAC, ROHS
IP 20
Product type Routers
Weight 2 kg
Warranty 12 months
