Milesight UR35-L00AU-W-P - Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi
Milesight UR35-L00AU-W-P - Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi
Features
The Ursalink UR35 is a cost-effective industrial cellular router with embedded intelligent software features that are designed for multiple M2M/IoT applications. Global WCDMA and 4G LTE carrier support makes this device a must-have for operators trying to maximizing uptime.
Integrating an embedded cellular modem and dual SIM functionality, the UR35 provides 3G/4G cellular network speeds up to150 Mbps download and 50 Mbps upload, it also has 5 Ethernet ports and supports 802.11b/g/n Wi-Fi.
All of these capabilities deliver uninterrupted internet access. Easy deployment and comprehensive remote device management makes the UR35 versatile in most IoT/M2M applications.
- Dual SIM cards for backup between multiple carriers
- Ethernet, I/O, serial port and Wi-Fi for connecting end devices.
- Ursalink DeviceHub connectivity
- Embedded Python SDK for development
- Rugged enclosure, optimized for DIN rail or shelf mounting
Specifications
Technical Specifications
| CPU | 528 MHz, ARM Cortex A7z |
|---|---|
| Memory | 128 MB Flash, 128 MB DDR3 RAM |
| SIM Slots | 2 |
| Storage | 1 × Micro SD |
| Ports | 5 × RJ-45 (1 × WAN +4 × LAN (PoE PSE Optional on LAN ports) |
| Connectors | 2 x SMA, 1 x RP-SMA |
| Ports | 1 × RS232 + 1 × RS485 (Terminal Block) |
| Input Voltage | 9-48 VDC (48 V power input is needed for PoE output) |
| Power Consumption | = 7.9W (In Non-PoE mode) |
| Serial Interface | 1 × RS232 + 1 × RS485 (2 × RS485 Optional) |
| Baud Rate | 300bps to 230400bps |
| Power Output | 4 × 802.3 af/at PoE output |
| Ingress Protection | IP30 |
| Dimensions | 135 x 103 x 45 mm (5.31 x 4.06 x 1.77 in) |
| Mounting | Desktop, Wall or DIN Rail Mounting |
| Network Protocols | PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, RIPv1/v2, OSPF, DDNS, VRRP, HTTP, HTTPS, DNS, ARP, QoS, SNTP, Telnet, VLAN, SSH |
| Serial Port | Transparent (TCP Client/Server, UDP), Modbus Gateway (Modbus RTU to Modbus TCP) |
| Operating Temp | -40°C to +70°C (-40? to +158?) Reduced Cellular Performance Above 60°C |
| Storage Temp | -40°C to +85°C (-40? to +185?) |
| Freq Bands | 3G: B1/B2/B5/B8 WCDMA, 4G: B1/B2/B3/B4/B5/B7/B8/B28@ FDD LTE, B40@ TDD LTE |
Not happy? Return within 7 days of delivery for a full refund or exchange. Items must be unused and in original packaging. Contact contact@kwtech.co.nz to arrange.
| Brand | Milesight |
|---|---|
| Product Type | B2B - Networking & Routing |
| Weight | 0.5 kg |
