Panorama Antennas LPB-6-60-2SP - 4G/5G LTE Low Profile Panel Mount Smart Antenna 2m cable SMA

Features

4G / 5G LTE Low Profile Panel Mount Antenna with 2m cable and SMA connector.

Compatible with Robustel, Cradlepoint, DrayTek, and a wide range of other cellular routers.

The LPB-6-60 antenna is a cost effective omni-directional panel mount antenna for 4G/3G/2G and 5G devices from 617-960/1710-6000MHz.

This Antenna is an ideal solution for use in industrial and domestic environments with cellular modems/routers and Machine to Machine (M2M) wireless connectivity applications.

This LPB-6-60 requires a conductive ground plane of >300mm (1') diameter for optimal performance.

Specifications

Technical Specifications

Pattern Omnidirectional
Max Input Power(W) 30
Frequency Range | Gain 617 - 960MHz | 3dBi; 1710 - 2700MHz | 4dBi; 3400 - 3800MHz | 8dBi; 4900 - 6000MHz | 9dBi
Cellular LTE Elements SiSo
WIFI Elements No
UHF Elements No
Number of GPS Elements No
Colour Black
Height 82 (mm) | 3.23 (in)
Diameter 48 (mm) | 1.89 (in)
Operating Temperature -40°/ +85°C (-40.0°/ +185.0°F)
Cable Length - LTE min: 2 (m) | 6.56 (ft); max: 5 (m) | 16.4 (ft)
Cable Type (LTE) CS29
Connector (LTE) SMA (m)
Mounting Type Fixed Mast; Panel; Wall
Mounting Methods Mast; Panel; Wall
IP Rating IP66
Technology 4G/5G; 5G; 2G/3G; 2G/3G/4G; Band 71 600MHz ready
