Panorama Antennas WMM4G-6-60-5SP - Outdoor Directional Wideband Antenna 2G/3G/4G/5G 4 x 5m cables SMA
Panorama Antennas WMM4G-6-60-5SP - Outdoor Directional Wideband Antenna 2G/3G/4G/5G 4 x 5m cables SMA
Features
The WMM4G-6-60 is a high directional gain 4x4 MiMo signal boosting antenna for 4G and 5G networks. Incorporating four separately fed wideband element assemblies in a single housing the WMM4G-6-60 is equipped to provide client side MiMo support for 4G and 5G networks offering 6dBi of peak gain at 617- 960MHz and 9dBi peak gain at 1710-6000MHz.
The weather resistant housing is designed for wall mounting and wall and mast mount brackets are provided. Supplied with fitted low loss double shielded cable for cellular/LTE the WMM4G-6-60 minimises exposed connector joints and simplifies cable management for easy installation.
- Supports Cat18/20 (617-960/1710-6000MHz) 4x4 MiMo 4G/5G
- High Directional gain 6-9dBi
- Wall Mount or Mast Mount
- Ideal for Branch Networks and Failover
Specifications
Technical Specifications
| LTE Frequencies | 617-960/1710-6000MHz |
|---|---|
| Typical VSWR | <2:1 |
| Peak Gain (dBi) | 9 |
| LTE MiMo | 4x4 |
| Max Input Power (W) | 50 |
| Pattern | Directional |
| Available Colours | White |
| Length (mm) | 507 |
| Width (mm) | 307 |
| Height (mm) | 87 |
| Operating Temperature | -40 / +80° C |
| Mounting Type | Wall Mount; Mast Mount |
| Mounting Method | Wall Bracket; Mast Clamp; U Bolt; Screw Mount; Flush Mount |
| IP Rating | IP66 |
Not happy? Return within 7 days of delivery for a full refund or exchange. Items must be unused and in original packaging. Contact contact@kwtech.co.nz to arrange.
| Brand | Panorama Antennas |
|---|---|
| Product Type | B2B - Networking & Routing |
| Weight | 0.5 kg |
