Phanteks M25 G2 120mm PWM ARGB Fan Black, Single Pack
Features
High Value Daisy-Chained Fan
The Phanteks M25 Gen2 comes packed with features previously only seen in the highest end fans. It's Daisy-chain Unified Fan Frame easily interlocks with the next fan to link multiple fans together into one.
With its blades designed specifically for high airflow performance on radiators and heat sinks, the M25 Gen2 excels where it matters. Delivering low temperatures with a clean look to elevate your system.
Single Cable Solution
- The Linq6 connector consolidates both fan and lighting controls into one cable for a cleaner, more efficient build.
- Integrated D-RGB Lighting, features smooth, dynamic lighting with an infinity mirror effect for striking visuals.
Daisy-Chain Unified Fan Design
- Easily connect multiple fans with a streamlined setup, minimizing clutter.
- Connect fans easily by sliding and locking with a screw.
- Sleek Aesthetic, included screw covers provide a polished and professional look.
Versatile Airflow Options
- Choose between regular and reverse airflow models for optimal system configuration.
- High Cooling Performance, designed to excel on radiators and heat sinks for efficient thermal management.


Specifications
Technical Specifications
| Frame Size | 120 x 120 x 25 mm | 4.72 x 4.72 x 0.98 in |
|---|---|
| Blade Geometry | Nine blades design |
| Color | Black |
| Connector | Linq6 |
| Cable Length | 120 mm | 4.72 in Daisy-chain |
| Bearing Type | Hydraulic bearing |
| Rated Voltage | 12V |
| Noise Level | 35.13 dBA |
| Max. Airflow | 72.72 CFM |
| Max. Air Pressure | 2.51 mm H2O |
| Speed | 350~2000 ± 10% RPM |
| MTFB | 40.000 hours |
| Max Current | 0.30A |
| Max Power | 2.76W |
| Operating Voltage Range | DC 6 - 13.2V |
| LED Number | 12 |
| LED Rated Current | Max. 0.43A |
| Bearing Type | Hydraulic bearing |
| Rated Voltage | 12V |
| Noise Level | 39.28 dBA |
| Max. Airflow | 73.69 CFM |
| Max. Air Pressure | 1.99 mm H2O |
| Speed | 350~2000 ± 10% RPM |
| MTFB | 40.000 hours |
| Max Current | 0.30A |
| Max Power | 2.76W |
| Operating Voltage Range | DC 6 - 13.2V |
| LED Number | 12 |
| LED Max Rated Current | 0.43A |
| Net Weight | 154 ± 5 g | 5.43 ± 0.17 oz |
| Gross Weight | 224 ± 5 g | 7.90 ± 0.17 oz |
| Scope of Delivery | 1x M25G2-120 fan |
| Accessories | 1x 500 mm Linq6 extension cable4x Screw cover corner2x Screw cover bridge |
| Screws | 5x Fan screw |
| Brand | Phanteks |
|---|---|
| Product Type | PC Parts |
