POWERSHIELD Centurion RT LiFePO4 3000VA Lithium-ion Online UPS. True double-conversion. Output
Features
PowerShield Centurion RT LiFePO4 3000VA
The Centurion LiFePO4 features true online double conversion and a Lithium-iron Phosphate advantage that includes extended battery life, lighter weight, faster recharge, higher performance and higher power density. As our highest single phase power density UPS, this sophisticated range will provide the most comprehensive protection for mission-critical devices such as sensitive networks, computers, servers, telecom applications, as well as industrial applications.
- True double-conversion
- HID Communication via USB
- Output power factor 0.9
- User-friendly and electronic easy-shift LCD display
- Rack or Tower design
- Advanced ECO mode for energy saving
- Generator compatible
- Programmable power management outlets
- Emergency Power Off function (EPO)
- Hot swappable battery design
- Available in 1000, 2000 and 3000 VA models
- Ideal for medium density power protection
- Extra large charger
Download data sheet: https://powershield.com.au/wp-content/uploads/brochures/CenturionRT_LiFePO4_Brochure.pdf
Specifications
Technical Specifications
| Model Number | PSLCERT3000 |
|---|---|
| Capacity | 3000VA/2700W |
| Topology | True online double- conversion,Pure Sine Wave |
| Frequency Range | 40Hz - 70Hz |
| Phase | Single phase with ground |
| Power Factor Correction | 0.99 @ nominal voltage (100% load) |
| Low Line Transfer | 160Vac / 140Vac / 120 / 110Vac ± 5 %(based on load percentage 100%-80% / 80%-70% / 70%-60% / 60%-0) |
| Low Line Comeback | 175Vac / 155Vac / 135Vac / 125Vac ± 5 % |
| High Line Transfer | 300Vac ± 5 % |
| High Line Comeback | 290Vac ± 5 % |
| Output Power Factor | 0.9 |
| Output Voltage (AC Mode) | 240Vac (Selectable 200/208/220/230/240Vac) |
| Voltage Regulation (Batt. Mode) | ± 1% |
| Frequency Range (Batt. Mode) | 50Hz or 60Hz ±1Hz |
| Current Crest Ratio | 3:1 (max.) |
| Waveform (Batt. Mode) | Pure Sine Wave |
| IEC Outlets 1 | 10A, C13 x 5 | 16A, C19 x 1 |
| Australian Sockets | 2 |
| AC Mode to Batt. Mode | Zero |
| Inverter to Bypass | 4ms (Typical) |
| ECO Mode (Advanced) | 97% |
| Battery Mode | 89% |
| Battery | LiFePO4 |
| Typical Recharge Time | 2 hours |
| Backup Time:25% Load50% Load75% Load100% Load | 44 mins22 mins14 mins11 mins |
| Full Protection | Overload, discharge, thermal, short circuit and overcharge protection |
| Surge Protection | 1872 Joules / 39000 Amps |
| Interface | USB or RS232 as standard, Intelligent slot for PSSNMP, PSModbus or PSAS400 dry contact |
| Software | PowerShield® NetGuard® software - supports Windows, Linux, Unix and Mac based operating systems |
| HID | Supports Windows, Apple, Linux, NAS and various industrial controllers |
| LCD | Display/Alarm UPS Status, Load & Battery Level, Input/Output Voltage, Batt. Time Remaining and Fault Indicators |
| Audible Alarm | Battery Mode, Bypass Mode, Low Battery (Batt. Mode), Fault, Overload |
| Dimension, (D x W x H) mm | 600 x 438 x 88 |
| Weight (kg) | 19.7 |
| Temperature | 0 - 40°C |
| Humidity | 20 - 90% (RH Non-condensing) |
| Noise Level | < 50dBA @ 1 Meter |
| Safety / EMC / RoHS | EN62040-1-1 2003, IEC60950-1-1 / EN62040-2 2006 / Directive 2011/65/EU |
| Brand | POWERSHIELD |
|---|---|
| Product Type | Power & Charging > UPS & Power Distribution |
| Weight | 24.0 kg |
