RBwAPR-2nD&R11e-LR9G - MikroTik wAP LR9G kit with 900MHz LoRa and 2.4GHz WiFi
RBwAPR-2nD&R11e-LR9G - MikroTik wAP LR9G kit with 900MHz LoRa and 2.4GHz WiFi
Features
wAP LR9G kit
The wAP LR9G kit is a rugged, out-of-the-box LoRa® 915 MHz gateway built into MikroTik's proven wAP form factor.
- LoRa® 915 MHz support
- Built-in GPS (via MT3337V)
- Improved Rx sensitivity: up to -141 dBm
- 2.4 GHz Wi-Fi (802.11b/g/n dual-chain)
- Passive PoE support and wide voltage input range
- 3 power input options: PoE, automotive, or DC jack
- SMA female connectors for external antenna options
Pair it with any public or private LoRa® network (including The Things Network or The Things Industries) using the preinstalled UDP packet forwarder. Whether you're deploying smart irrigation in a field or setting up a LoRa® node on a building rooftop - this device is made to withstand the elements and simplify setup.
* The device has no built in LTE modem, the SIM slot can only be used, if LoRa interface card is removed and replaced by an LTE modem
Specifications
Technical Specifications
| MPN | RBwAPR-2nD&R11e-LR9G |
|---|---|
| Architecture | MIPSBE |
| CPU | QCA9531 |
| CPU core count | 1 |
| CPU nominal frequency | 650 MHz |
| RouterOS license | 4 |
| Operating System | RouterOS v7 |
| Size of RAM | 64 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 60°C |
| Number of DC inputs | 3 (DC jack, PoE-IN, Automotive) |
| DC jack input Voltage | 9-28 V |
| Automotive input Voltage | 12-30 V |
| Max power consumption | 7 W |
| PoE in | Passive PoE |
| Cooling type | Passive |
| PoE in input Voltage | 9-28 V |
| Wireless 2.4 GHz Max data rate | 300 Mbit/s |
| Wireless 2.4 GHz Number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 2 |
| Wireless 2.4 GHz chip model | QCA9531 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
| 10/100 Ethernet ports | 1 |
| Number of SIM slots | 1 Modem (Mini SIM) |
| MiniPCI-e slots | 1 |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| GPS RF connector type | uUFL |
| Certification | FCC, IC, EAC |
| IP | 54 |
