REXTRON PAAG-E3114 - 4 Port USB-A KVM Switch w/ Audio & Hotkey Control. 4 Computers Share Up to 4x USB
Features
REXTRON 4 Port USB-A KVM Switch with Audio & Hotkey Control. 4 Computers Share Up to 4x USB HID Peripherals. Supports VGA, DVI, HDMI, DP. Supports 4K @ 60Hz
The PAAG-E3114 4 Ports True 4K DisplayPort KVM Switch lets you control two 4K resolution DisplayPort computers with one set USB Keyboard, Mouse, USB Devices and monitor. You can easily switch between four 4K 60Hz DisplayPort computers using our 4K 60Hz DisplayPort KVM switch which incorporated user friendly hotkey control. And Real-time USB HID port provides you amazing seamless HID switching experience and USB 3.2 Gen 1 port provides excellent I/O speed.
Rextron KVM switch with USB Hub supports not only keyboard mouse operation but also USB 3.2 Gen 1 peripherals sharing without any software or driver installation. Users can either perform computers switching independently or switch computers in conjunction with USB concurrently. Dedicated USB 3.2 Gen 1 port designed on the front and rear side of the KVM switch unit suitable for both long-term and temporary USB peripherals access allows users to attach or detach USB devices with ease.
- 4 Computers Share USB Console & USB 3.2 Gen 1 Devices
- Support DisplayPort 1.2
- Support Resolution Up to 4K 60Hz ( 4:4:4 )
- No Software & Driver Required
- Auto Scan & Adjustable Scan Time Interval
- Hotkey Control for Quick Operation
- Support Windows and Mac Host Systems
Specifications
Technical Specifications
| Model Name | PAAG-E3114 |
|---|---|
| Computer/Server Ports ( input ) | DisplayPort x 4 ( Single Display x 4 PCs )USB 3.2 Gen 1 Type B x 4Audio Jack in x 4 |
| Console Ports ( output ) | DisplayPort x 1 ( Single Display )USB 3.2 Gen 1 Type A x 2( Rear & Front )USB HID Type A x 4( Rear & Front )Audio Jack out x 1 |
| Video Resolution ( Max. ) | 3840x2160 @ 60Hz( 4:4:4 )4096x2160 @ 60Hz( 4:4:4 ) |
| Push Button | Port Selection x 1 |
| LED Indicator ( Power / Status ) | Computer Ready x 2 ( Green )Computer Selected x 2 ( Red ) |
| Automatic scan interval | 3, 8, 15, 30 seconds |
| Enclosure | Metal |
| Power Supply | DC 9~12V |
| Brand | REXTRON |
|---|---|
| Product Type | PC Peripherals > KVM Switches & Cables |
| Weight | 3.084 kg |
| Warranty |
|---|
