StarTech.com 120B-USBC-MULTIPORT - USB C MULTIPORT ADAPTER DUAL 4K HDMI PD
Features
This USB Type-C Multiport Adapter with DP 1.4 Alternative Mode, DSC and MST, supports dual-HDMI® (HDR) video with resolutions of up to 4K 60Hz uncompressed video. The mini travel dock turns your Dell XPS, Lenovo X1 Carbon, HP Elite/ProBook, or other USB-C laptop into a workstation, anywhere you go. The USB-C docking station provides dual HDMI outputs, a 2-port USB 3.2 Gen 1 Type-A (5Gbps) Hub including a BC 1.2 port to power and charge a USB peripheral, SD and MicroSD card readers, and a Gigabit Ethernet port, all through one connection to your laptop's USB-C or Thunderbolt 3/4™ port. In addition, it offers advanced charging through USB Power Delivery (PD) 3.0 pass-through via an integrated 12-inch (30 cm) USB-C host cable, for more set up flexibility.
High-Performance Dual-HDMI Video via MST
The compact docking station connects your laptop to two HDMI monitors, creating a powerful workstation. It supports DP 1.4 Alt Mode with DSC and MST, for uncompressed video performance up to dual 4K (3840 x 2160p) at 60Hz, depending upon your host computer. The dock also supports the use of ultrawide monitors.
Connect Your Devices
The USB-C to USB 3.2 Gen 1 (5Gbps) hub provides two USB-A ports for connecting your USB devices.
Multiple Use Cases
A versatile dock solution for use at your office desk, home office, hotel desk, or in the boardroom. It's portable enough to be carried in your bag / backpack for mobile use. The USB-C dock can operate with bus-power alone, , or with a USB-C power adapter connected to the pass-through port - for full laptop and peripheral charging. The lightweight docking station features a built-in 12 in (30 cm) USB-C host cable.
Built-In SD Card Reader
Access your multimedia content with ease. The multiport adapter provides direct access to your SD / SDHC™ / SDXC™ or microSD (uSD) memory cards.
Charge Your Laptop and Peripherals
With support for USB PD 3.0 (up to 100W), the USB Type-C multiport adapter enables you to power and charge your laptop and a USB peripheral, when a USB-C power adapter is connected to the pass-through port. PD 3.0 features Fast Role Swap (FRS) which prevents USB data disruption when switching power sources (e.g., USB-C power adapter to bus power).
Reliable Network Connectivity
The Gigabit Ethernet port ensures reliable wired network access. Support for WoL allows you to boot the host computer from a remote location.
Specifications
Technical Specifications
| External Ports | 2 - HDMI (19 pin)2 - USB 3.2 Gen 1 Type-A (9 pin, 5Gbps)1 - RJ-451 - SD Slot1 - MicroSD1 - USB Type-C (24 pin) USB Power Delivery Only |
|---|---|
| Host Connectors | 1 - USB 3.2 Type-C (24 pin, Gen 1, 5Gbps) |
| Operating Temperature | 0°C to 45°C (32°F to 133°F) |
| Storage Temperature | -10°C to 70°C (14°F to 185°F) |
| Humidity | 10~90% RH (Non-condensing) |
| 4K Support | Yes |
| Fast-Charge Port(s) | Yes |
| Displays Supported | 2 |
| Interface | USB 3.2 Gen 1 |
| Bus Type | USB-C |
| Industry Standards | HDMI 2.0HDR10DisplayPort 1.4USB 3.2 Gen 1 (5Gbps)USB Power Delivery Specification Rev. 3.0 |
| Chipset ID | VIA - VL102VIA - VL817NOREL Systems - NS1081ASIX - AX88179ASynaptics - VMM6210 |
| LED Indicators | 1 - Connection state/activity LEDs under GbE port. |
| Package Length | 5.6 in [14.2 cm] |
| Package Width | 6.9 in [17.5 cm] |
| Package Height | 1.2 in [3.0 cm] |
| Shipping (Package) Weight | 6.3 oz [179.0 g] |
| Maximum Data Transfer Rate | 5 Gbps |
| Maximum Digital Resolutions | Up to dual 4K (3840 x 2160p) 60Hz |
| Type and Rate | USB 3.2 Gen 1 - 5 Gbit/s |
| UASP Support | Yes |
| Compatible Networks | 10/100/1000 Mbps |
| Full Duplex Support | Yes |
| Color | Space Gray |
| Product Length | 2.3 in [5.9 cm] |
| Product Width | 5.7 in [14.5 cm] |
| Product Height | 0.6 in [1.4 cm] |
| Weight of Product | 5.8 oz [165.0 g] |
| Material | Aluminum |
| Cable Length | 11.8 in [30 cm] |
| Power Source | Bus Powered and Host USB-C Power Adapter |
| Power Consumption (In Watts) | 15W |
| OS Compatibility | Windows® 7, 8, 8.1, 10, 11Chrome OS™ |
| Brand | StarTech.com |
|---|---|
| Product Type | PC Peripherals > Adapters |
| Weight | 0.082 kg |
| Warranty |
|---|
