TASCAMDR70D - TASCAM DR70D PORTABLE 4 TRACK PCM RECORDER FOR DSLR VIDEO PRODUCTION
$583.33
Free shipping over $299
Genuine product
7-day returns
TASCAMDR70D - TASCAM DR70D PORTABLE 4 TRACK PCM RECORDER FOR DSLR VIDEO PRODUCTION
Features
Designed as an audio recording solution for filmmakers, the DR-70D 4-Channel Audio Recording Device for DSLR and Video Cameras from Tascam features dual built-in omnidirectional microphones and is capable of recording up to 4 tracks simultaneously. It has tripod mounts on both the top and bottom of the unit and can be mounted above or below your DSLR or video camera as well as on a follow-focus cage.
Recording to SD, SDHC, or SDXC cards up to 128GB, the DR-70D tracks in BWAV format for NLE compatibility. All integral parameters feature dedicated hardware controls, so you never have to go searching through menus to quickly change a setting. A dedicated camera output lets you send a mic-level signal to your camera's audio input to create a reference track for easier synching in post, while the dedicated headphone output allows you to monitor your audio.
- Designed for use with video and DSLR cameras and can be screwed to the bottom of a DSLR camera with jacks and controls that stay out of the way
- Simplified interface with controls on hardware switches and knobs instead of menus, for quick adjustment during a take
- Dual record function captures a safety track to have a backup in case of distortion
- Tascam's HDDA microphone preamps which are designed for low noise, low distortion, and full-bandwidth
- BWAV format capture for NLE compatibility
- Limiter and high-pass filter prevent wind or mic bumps from overdriving the recording
- Microphone level camera output allows you to record the same audio to the camera for easy synchronization in your editor
- Records to SD/SDHC/SDXC media
- Individual headphone and camera outputs allows you to monitor recording with headphones while sending another output to the camera
- Slate function records a tone for precise synchronization between DR-70D and camera audio in post
- 4-track recording records from four XLR microphone inputs
- Built-in omnidirectional microphones allow you to record without packing mics
- Runs on 4 AA batteries
Recording to SD, SDHC, or SDXC cards up to 128GB, the DR-70D tracks in BWAV format for NLE compatibility. All integral parameters feature dedicated hardware controls, so you never have to go searching through menus to quickly change a setting. A dedicated camera output lets you send a mic-level signal to your camera's audio input to create a reference track for easier synching in post, while the dedicated headphone output allows you to monitor your audio.
- Designed for use with video and DSLR cameras and can be screwed to the bottom of a DSLR camera with jacks and controls that stay out of the way
- Simplified interface with controls on hardware switches and knobs instead of menus, for quick adjustment during a take
- Dual record function captures a safety track to have a backup in case of distortion
- Tascam's HDDA microphone preamps which are designed for low noise, low distortion, and full-bandwidth
- BWAV format capture for NLE compatibility
- Limiter and high-pass filter prevent wind or mic bumps from overdriving the recording
- Microphone level camera output allows you to record the same audio to the camera for easy synchronization in your editor
- Records to SD/SDHC/SDXC media
- Individual headphone and camera outputs allows you to monitor recording with headphones while sending another output to the camera
- Slate function records a tone for precise synchronization between DR-70D and camera audio in post
- 4-track recording records from four XLR microphone inputs
- Built-in omnidirectional microphones allow you to record without packing mics
- Runs on 4 AA batteries
Specifications
Technical Specifications
| Media | SD card (64 MB to 2 GB)SDHC card (4 to 32 GB)SDXC card (48 to 128 GB) |
|---|---|
| Recording Format | WAV & BWF 44.1 to 96 kHz, 16/24-bit |
| Number of Channels | 4 channels (2x stereo or 4x mono) |
| Connector | 4x Combo XLR/TRS Connectors (1: Ground, 2: Hot, 3: Cold) |
| Input Impedance | Mic/Mic + Phantom Power: 2 kOhmsLine: 10 kOhms or more |
| Phantom Power | 48 V +/-4 V(10 mA/CH), 24 V +/-4 V(10 mA/CH) |
| Input Level | Mic/Mic + Phantom Power: 0 dBu standard, -72 dBu maximumLine: +4 dBu standard, +20 dBu maximum |
| Mic Input | Mic Input Gain: +11 dB (low), +51 dB (High), +64 dB (Hi + Plus) |
| Connector | 1/8" (3.5 mm) stereo mini jack (this connector can be supplied plug-in power) |
| Input Impedance | 10 kOhms |
| Input Level | Minimum Input Level: -50 dBVMaximum Input Level: +10 dBV |
| Input Gain | Mic Input Gain: +3 dB (Low), +26 dB (High), +38 dB (High + Plus) |
| Connector | 1/8" (3.5 mm) stereo mini jack |
| Input Impedance | 10 kOhms |
| Input Level | Standard Input Level: -10 dBVMaximum Input Level: +6 dBV |
| Line Output | Connector: 1/8" (3.5 mm) stereo mini jackOutput Impedance: 200 ohmsStandard Output Level: -10 dBVMaximum Output Level: +6 dBV |
| Camera Out | Connector: 1/8" (3.5 mm) stereo mini jackOutput Impedance: 200 ohmsStandard Output Level: -40 dBVMaximum Output Level: -24 dBV |
| Connector | 1/8" (3.5 mm) stereo mini jack |
| Maximum Output Level | 20 mW + 20 mW |
| Connector | Micro-B type |
| Format | USB 2.0 High Speed mass storage class |
| Input | 2.5 mm TRS jack (remote sold separately) |
| Power Source | 4x AA batteries (Alkaline or Ni-MH)USB Bus powerOptional AC AdapterOptional Battery pack |
| Power Consumption | 5 W |
| Frequency Response | 20 Hz to 20 kHz +0.5/-2 dB (LINE IN or MIC IN to LINE OUT, Fs 44.1/48 kHz, JEITA)20 Hz to 40 kHz +0.5/-3 dB(LINE IN or MIC IN to LINE OUT, Fs 96 kHz, JEITA) |
| Distortion | 0.02% or less (LINE IN or MIC IN to LINE OUT Fs 44.1/48/96 kHz, JEITA) |
| Signal to Noise Ratio | 92 dB or more (LINE IN or MIC IN to LINE OUT Fs 44.1/48/96 kHz, JEITA) |
| Equivalent Input Noise | -120 dBu or less |
| Windows | OS: XP, Vista, 7, 8, 8.1CPU: Pentium 300 MHz or betterRAM: 128 MB or moreUSB: 2.0 recommended |
| Mac | OS: OS X 10.2 to 10.9CPU: Power PC, iMac, G3, G4, 266 MHz or moreRAM: 64 MB or moreUSB: 2.0 recommended |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Dimensions (W × H × D) | 6.65 x 2.2 x 4.2" (169 x 55.2 x 106.5 mm), with top adapter attached |
| Weight With Batteries: | 1.37 lb (625 g) |
| Without Batteries: | 1.16 lb (530 g) |
