TL-MC210CS - TP-Link Gigabit Ethernet Media Converter (SC, single-mode), Extends Up to 15km
TP-Link

TL-MC210CS - TP-Link Gigabit Ethernet Media Converter (SC, single-mode), Extends Up to 15km

SKU: TL-MC210CS ● In Stock
$46.26
Free shipping over $299 Genuine product 7-day returns

TL-MC210CS - TP-Link Gigabit Ethernet Media Converter (SC, single-mode), Extends Up to 15km

Overview

The MC210CS is a media converter designed to convert 1000BASE-LX fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-LX standards, the MC210CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC210CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on both transmitting and receiving data. Auto MDI/MDI-X for TX port, and front panel status LEDs. The MC210CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 9.3 miles (15km).

  • 10/100/1000Mbps Auto-Negotiation RJ45 port supporting Auto-MDI/MDIX
  • Complies with IEEE 802.3ab and IEEE 802.3z
  • Extends fiber distance up to 9.3 miles (15km)

Technical Specifications

Maximum data transfer rate 1000
Networking standards IEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3z
Ethernet interface type Gigabit Ethernet
Copper ethernet cabling technology 1000BASE-LX,1000BASE-T
Auto MDI/MDI-X Y
Cable types supported Cat5,Cat5e
Maximum transfer distance 15000
Wavelength 1310
Fiber mode structure Single-mode
Internal N
LED indicators Y
Product colour Black
Connectivity technology Wired
Ethernet LAN (RJ-45) ports 1
Fiber ports quantity 1
Fiber optic connector SC
Power consumption (max) 1.8
Width 95
Depth 73
Height 27
Operating temperature (T-T) 0 - 40
Storage temperature (T-T) -40 - 70
Operating relative humidity (H-H) 10 - 90
Storage relative humidity (H-H) 5 - 90
Compliance certificates RoHS
Harmonized System (HS) code 85176990
