TL-SM5110LSA-10 - TP-Link SM5110LSA-10 Omada 10GBase-BX WDM Bi-Directional SFP+ LC Module
TP-Link

TL-SM5110LSA-10 - TP-Link SM5110LSA-10 Omada 10GBase-BX WDM Bi-Directional SFP+ LC Module

SKU: TL-SM5110LSA-10 ● In Stock
$65.17
Free shipping over $299 Genuine product 7-day returns

TL-SM5110LSA-10 - TP-Link SM5110LSA-10 Omada 10GBase-BX WDM Bi-Directional SFP+ LC Module

Overview

The SM5110LSA-10 is designed to extend transmission distance up to 10km with a maximum rate of 10Gbps. It is a single-mode SFP+ transceiver that supports bi-directional data transmission, which is cost-saving.

  • Supports WDM Bi-Directional technology, using a single strand of fiber, cost saving
  • Single mode SFP+ LC Transceiver
  • Hot-Pluggable with maximum flexibility
  • Supports Digital Diagnostic Monitoring (DDM)
  • Compatible with 10G Small Form Pluggable Multi-Source Agreement (SFP+)
  • Compatible with switches with 10G ports like SG3428X and SG3452X

Technical Specifications

SFP transceiver type Fiber optic
Maximum data transfer rate 10312
Interface type SFP+
Single-mode fiber (SMF) supported Y
Fiber optic connector LC (UPC)
Fiber cable diameters supported (core/cladding) 9/125
Maximum transfer distance 10000
Tx wavelength (max) 1330
Rx wavelength (max) 1270
Networking standards IEEE 802.3ae
Digital Diagnostics Monitoring (DDM) Y
Product colour Silver
Hot-swap Y
Input voltage 3.3
Compliance certificates CE,Federal Communications Commission (FCC),RoHS
Minimum operating temperature 0
Maximum operating temperature 70
Operating temperature (T-T) 0 - 70
Storage temperature (T-T) -40 - 85
Operating relative humidity (H-H) 10 - 90
Storage relative humidity (H-H) 5 - 90
Width 57
Depth 14
Height 12
Quantity per pack 1
Manual Y
