Transcend Embedded 512MB SD Card, SLC mode, Wide Temp.

SKU: TS512MSDC220I ● In Stock

$48.07 ~~$60.72~~

Free shipping over $299 Genuine product 7-day returns

Features

Transcend's SLC Mode technology is a cost-effective solution that offers performance close to that of SLC NAND flash. SDC220I SD Cards combine the advantages of high performance and exceptional endurance at an affordable price. The wide temperature(-40 ~ 85C) capability and high compatibility make them ideal for demanding industrial applications such as POS terminals, medical devices as well as portable devices equipped with an SD memory card slot.

Firmware Features

- Built-in ECC (Error Correction Code) functionality
- Early Move
- Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
- Wear-Leveling

Hardware Features

- Compliant with RoHS 2.0 standards
- Electrostatic protection (ESD IEC 61000-4-2)
- Compliant with SD specification 3.01
- High-quality MLC NAND flash and SLC mode (also called SuperMLC) for exceptional endurance and reliability
- Promised operational reliability in a wide temperature range (from -40°C to 85°C)
- Supports Transcend Scope Pro software

Specifications

Technical Specifications

Dimensions	24 mm x 32 mm x 2.1 mm (0.94" x 1.26" x 0.08")
Form Factor	SD flash card
Flash Type	MLC NAND flash (SLC mode)
Capacity	512MB
Operating Voltage	2.7V ~ 3.6V
Drop Test	1.5m free fall
Wide Temp.	-40°C (-40°F) ~ 85°C (185°F)
Storage Temperature	-40°C (-40°F) ~ 85°C (185°F)
Humidity	0% ~ 95%
Shock	Acceleration: 490 m/s² (standard holding time: 11 ms, semi-sine wave, velocity change: 3.44 m/s)
Vibration (Operating)	20 G (peak-to-peak), 20 Hz ~ 2,000 Hz (frequency)
Power Consumption (Max.)	0.72 watt(s)
Read Speed (Max.)	up to 22 MB/s
Write Speed (Max.)	up to 20 MB/s
Terabytes Written (TBW)	up to 66 TBW
