Ubiquiti 24-port (8) 2.5 GbE PoE++ (16) 10 GbE

Ubiquiti 24-port (8) 2.5 GbE PoE++ (16) 10 GbE

Name: Ubiquiti 24-port (8) 2.5 GbE PoE++ (16) 10 GbE
Brand: Ubiquiti
SKU: USW-PRO-XG-24-POE
Price: 4468.98 NZD
Availability: InStock

SKU: USW-PRO-XG-24-POE ● In Stock

$3,886.07

inc GST ▲ +GST

Free shipping over $299 Genuine product 7-day returns

Features

Professional-grade, 24-port Layer 3 Etherlighting™ PoE+++ switch with (16) 10 GbE, (8) 2.5 GbE, and (2) 25G SFP28 ports.

Specifications

Technical Specifications

Switching Capacity	460 Gbps
Total Non-Blocking Throughput	230 Gbps
Forwarding Rate	342 Mpps
Supported VLANs	1,000
MAC Address Table Size	128,000
ARP Entries	128,000
IPv4 Routes	256,000
Packet Buffer Size	8 MB
DHCP Server (Local Networks)	Yes
DHCP Relay	Yes
Inter-VLAN Routing (Local Networks)	Yes
Static Routing (Local Networks)	Yes
LACP Port Aggregation	Yes
STP & RSTP	Yes
QoS (DSCP)	Yes
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)	Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)	Yes
IGMP Snooping	Yes
802.1X Control	Yes
MAC-Based ACLs & Device Isolation	Yes
DHCP Snooping & Guarding	Yes
Egress Rate Limit	Yes
Flow Control	Yes
Storm Control	Yes
Multicast & Broadcast Rate Limiting	Yes
MAC Address Blocking	Yes
IP-Based ACLs & Network Isolation	Yes
MAC-Based Port Restriction	Yes
Port Isolation	Yes
Port Mirroring	Yes
Jumbo Frames	Yes
LLDP-MED	Yes
Voice VLAN	Yes
Loop Protection	Yes
PoE Ports	PoE+++24
Max. PoE Wattage per Port by PSE	PoE15.4WPoE+30WPoE++60WPoE+++90W
Max. Power Consumption	150W (Excluding PoE Output)870W (Including PoE Output)
Power Method	(1) Universal input, 100-240V AC, 50/60 Hz(1) USP RPS DC input
Power Input Method	AC input
Power Supply	AC/DC, internal, 870W
Supported Voltage Range	100-240V AC
Ethernet	AR
Weight	Without mounting brackets: 7.9 kg (17.4 lb)With mounting brackets: 8 kg (17.6 lb)
Enclosure Material	SGCC steel
Mount Material	SGCC steel
Supported Rack Depth	482.6 mm (19") four-post racks
LCM Display	1.3" touchscreen
ESD/EMP Protection	Air: ± 30kV, contact: ± 20kV
Ambient Operating Temperature	-5 to 40° C (23 to 104° F)
Ambient Operating Humidity	10 to 90% noncondensing
Ethernet	Yes
SFP28	Yes
RPS	Yes
NDAA Compliant	Yes
Certifications	CE, FCC, IC
Application Requirements	UniFi Network Version 9.1.120 and later
