Ubiquiti UniFi U7 Pro XG Ceiling-mounted 6-stream Tri-Radio WiFi 7 Access Point with 10/5/2.5/1 GbE support - Black
Features
The Ubiquiti UniFi U7 Pro XG Black (U7-Pro-XG-B) is a cutting-edge enterprise-grade Wi-Fi 7 access point designed for high-density environments that demand ultra-fast, reliable, and scalable wireless connectivity. Part of Ubiquiti's next-generation UniFi lineup, the U7 Pro XG offers top-tier performance with support for the latest Wi-Fi 7 (802.11be) standard, delivering significant improvements in speed, capacity, and latency over previous Wi-Fi generations.
This tri-band access point operates across the 2.4 GHz, 5 GHz, and the newly introduced 6 GHz spectrum, offering a total wireless throughput of up to BE11000 (11 Gbps aggregate). It is engineered to support numerous simultaneous users with low interference and exceptional efficiency, making it ideal for large venues such as stadiums, universities, hotels, and busy office spaces.
A standout feature of the U7 Pro XG is its 10 Gigabit Ethernet (10GbE) uplink, which ensures rapid data backhaul and maximizes throughput to match the high-speed wireless capabilities. It also supports PoE+ (Power over Ethernet Plus) for streamlined deployment using a single Ethernet cable for both data and power, with a maximum power consumption of approximately 22W.
Visually, the U7 Pro XG comes in a sleek black finish, adding a modern, professional aesthetic suited to visible installations in design-conscious environments. Like other UniFi devices, it is managed via the intuitive UniFi Network Controller, allowing centralized configuration, monitoring, firmware upgrades, and advanced network analytics.
In summary, the Ubiquiti U7 Pro XG Black offers enterprise-level performance, future-proof wireless technology, and user-friendly management - a robust solution for demanding networks that require reliability, speed, and scale.
Specifications
Technical Specifications
| Dimensions | 206 (diameter) x 32.5 mm |
|---|---|
| WiFi Standard | WiFi 7 |
| Spatial Streams | 6 |
| Coverage Area | 140 m² (1,500 ft²) |
| Max. Client Count | 300+ |
| Uplink | 10 GbE |
| Mounting | Ceiling, Wall (Lite Mount Included) |
| Power Method | PoE+ |
| MIMO | 6 GHz: 2 x 2 (DL/UL MU-MIMO)5 GHz: 2 x 2 (DL/UL MU-MIMO)2.4 GHz: 2 x 2 (DL/UL MU-MIMO) |
| Max. Data Rate | 6 GHz: 5.8 Gbps (BW320)5 GHz: 4.3 Gbps (BW240)2.4 GHz: 688 Mbps (BW40) |
| Antenna Gain | 6 GHz: 6 dBi5 GHz: 5 dBi2.4 GHz: 4 dBi |
| Max. TX Power | 6 GHz: 24 dBm5 GHz: 26 dBm2.4 GHz: 23 dBm |
| Max. BSSIDs | 8 per Radio |
| Supported Data Rates | 802.11be (WiFi 7)6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)802.11ax (WiFi 6)7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)802.11ac (WiFi 5)6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| Wireless Meshing | Yes |
| Band Steering | Yes |
| 802.11v BSS Transition Management | Yes |
| 802.11r Fast Roaming | Yes |
| 802.11k Radio Resource Management (RRM) | Yes |
| Advanced Radio Management | Yes |
| Passpoint (Hotspot 2.0) | Yes |
| Custom Branding Landing Page | Yes |
| Voucher Authentication | Yes |
| Payment-Based Authentication | Yes |
| External Portal Server Support | Yes |
| Password Authentication | Yes |
| Guest Network Isolation | Yes |
| Private Pre-Shared Key (PPSK) | Yes |
| WiFi Speed Limiting | Yes |
| Client Device Isolation | Yes |
| WiFi Schedules | Yes |
| RADIUS over TLS (RadSec) | Yes |
| Dynamic RADIUS-assigned VLAN | Yes |
| Max. Power Consumption | 22W |
| Supported Voltage Range | 42.5-57V DC |
| Networking Interface | (1) 10 GbE RJ45 port |
| Weight | 750 g (1.7 lb) |
| Management | Ethernet |
| Enclosure Material | UV-stabilized polycarbonate, aluminum alloy |
| Mount Material | Stainless steel (SUS304), galvanized steel (SGCC) |
| LEDs | System: White/Blue |
| Channel Bandwidth | HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz) |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
| Ambient Operating Temperature | -30 to 40° C (-22 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Application Requirements | UniFi Network: Version 9.1.120 and later |
| Brand | Ubiquiti |
|---|---|
| Product Type | Networking > Wireless Access Points |
| Weight | 0.5 kg |
