Vestel
Vestel XN86A-3F Vestel 86in Professional UHD Signage
$3,801.74
inc GST ▲
+GST
Free shipping over $299
Genuine product
7-day returns
You May Also Like
Features
Vestel XN86A-3F Vestel 86in Professional UHD Signage
Specifications
Technical Specifications
| Manufacturer part number | XN86A-3F |
|---|---|
| Model | XN86A-3F |
| Screen Size | 86" |
| Panel Technology | IPS |
| Backlight Type | Edge-Type LED |
| Brightness (typical) | 500 cd/m² |
| Native Resolution | 3840 x 2160 (16:9) - UHD |
| Contrast Ratio (typical) | 1200:1 |
| Dynamic Contrast Ratio | 50000:1 |
| Life Time (typical) | 50000 Hrs |
| Response Time (typical) | 8 ms |
| Active Area (H x V) | 1895 x 1066 mm |
| Viewing Angle | 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 |
| Color Value | 1.07 B (10-bit) |
| Screen Treatment | 2H |
| Haze Level | 28% |
| Refresh Rate | 120 Hz |
| Orientation | Horizontal / Vertical |
| Operation Hours | 24/7 |
| Area of Usage | Indoor |
| Mainboard Model | 135VS |
| RGB Input | VGA(DE-15F) |
| RGB Output | N/A |
| Video Input | 4xHDMI2.0, 1xDP1.2a, 2xUSB2.0, USB2.0(Internal) |
| Video Output | HDMI2.0, DP1.2a |
| Audio Input | Line In L/R |
| Audio Output | Headphone, Optic SPDIF |
| External Control | RS232(DE-9F), Ethernet(RJ45), Service(RJ12) |
| External Sensor | RJ12 |
| USB | Wifi Dongle |
| Product Dimensions (WxDxH) | 1928 x 80 x 1099 mm |
| Package Dimensions (WxDxH) | 2163 x 380 x 1405 mm |
| Product Weight | 62.2 kg |
| Package Weight | 83.5 kg |
| Vesa Mounting | 600 x 400 mm - M8 |
| Bezel Width | B/T/L/R:12 mm |
| Operating Temperature | 0-40°C |
| Operating Humidity | 10-90% |
| Power Supply | 110 VAC - 240 VAC - 50/60 Hz |
| Typical | 280 W |
| Deep Standby | <=0.5 W |
| Main Features | Open Content Management Support, Scheduler, USB-Autoplay, AutoLaunch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock, OSD Rotation, NoSignalPowerOff, Screen Saver, Pixe |
| Mechanical Features | Joystick, IR Extender Support, Rocker Switch, Detachable power cable, Carrying slots, Detachable logo positioning, Internal usb cover, Cable Holder |
| Optional Features | OPS Compliance |
| Speaker | 2 x 12 W |
| Standard | QSG, IB, Power Cord, Remote Control Unit, RC Battery, Mounting Kit, IR Extender Cable |
| Safety | YES |
| EMC | YES |
| CE | YES |
| Product type | Digital Signage |
| Weight | 1.01 kg |
| Warranty | 12 months |
| Brand | Vestel |
|---|---|
| Product Type | Digital Signage |
| Weight | 1.01 kg |
| Warranty |
|---|
