APC Smart-UPS X 3000VA Short Depth Tower
Features
Smarter productivity with ability to tailor to your specific application needs
Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds and notifications.
Save time with easy and convenient remote accessibility
Network manageable via serial, USB or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown and innovative energy management capabilities.
Low operating and maintenance costs with high efficiency, proven reliability and intelligent battery management
Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Dynamic battery replacement date indicator and automatic self tests insure battery reliability and warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed and manufactured by APC for over 23 years, Smart-UPS is the world's most trusted network UPS with over 25 million units sold.
Avoids costly power problems by keeping your IT equipment and data safe and available
Network grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems
Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry's most rigorous standards.
Specifications
Technical Specifications
| Output power capacity | 2.7 KWatts / 3.0 kVA |
|---|---|
| Max Configurable Power (Watts) | 2.7 KWatts / 3.0 kVA |
| Nominal Output Voltage | 230V |
| Output Voltage Distortion | Less than 5% |
| Output Frequency (sync to mains) | 50/60Hz +/- 3 Hz |
| Other Output | Voltages 208, 220, 240 |
| Load Crest Factor | 3 : 1 |
| Topology | Line Interactive |
| Waveform type | Sine wave |
| Output Connections | (2) IEC 320 C19 (Battery Backup)(2) IEC Jumpers (Battery Backup)(8) IEC 320 C13 (Battery Backup) |
| Transfer Time | 2-4 ms |
| Transfer Time | 6ms typical : 10ms maximum |
| Nominal Input Voltage | 208V, 230V |
| Input frequency | 50/60 Hz +/- 3 Hz (auto sensing) |
| Input Connections | IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A |
| Cord Length | 1,83 meters |
| Input voltage range for main operations | 140 - 280V |
| Number of Power Cords | 1 |
| Other Input Voltages | 220, 240 |
| Transfer Time | 2-4 ms |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Typical recharge time | 3 hour(s) |
| Expected Battery Life (years) | 3 - 5 |
| RBC Quantity | 1 |
| Extendable Run Time | 1 |
| Interface Port(s) | SmartSlot |
| Control panel console | LED status display with On Line : On Battery : Replace Battery and Overload indicators, Multi-function LCD status and control |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : configurable delays |
| Emergency Power Off (EPO) | Yes |
| Available SmartSlot™ Interface Quantity | 1 |
| Surge energy rating | 645 Joules |
| Data Line Protection | -- |
| Filtering | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Maximum Height | 432mm, 43.2CM |
| Maximum Width | 178mm, 17.8CM |
| Maximum Depth | 483mm, 48.3CM |
| Rack Height | 4U |
| Net Weight | 38.64 KG |
| Shipping weight | 47.73 KG |
| Shipping Height | 330mm, 33.0CM |
| Shipping Width | 586mm, 58.6CM |
| Shipping Depth | 633mm, 63.3CM |
| Color | Black |
| # of Layers per Pallet | 4.0 |
| # of Units per Layer per Pallet | 2.0 |
| Pallet Weight | 855.12 lbs. |
| Units per Pallet | 6.0 |
| Operating Temperature | 0 - 40 °C |
| Operating Relative Humidity | 0 - 95 % |
| Operating Elevation | 0-3000 meters |
| Storage Temperature | -15 - 45 °C |
| Storage Relative Humidity | 0 - 95 % |
| Storage Elevation | 0-15000 meters |
| Audible noise at 1 meter from surface of unit | 55.0 dBA |
| Online thermal dissipation | 184.0 BTU/hr |
| Brand | APC |
|---|---|
| Product Type | Power & Charging > UPS & Power Distribution > UPS |
| Weight | 21.646 kg |
| Warranty |
|---|
