ER603WP-4G-OUTDOOR - Omada ER603WP-4G-OUTDOOR 4G Cat4 N300 Outdoor PoE Gateway Router with 2x PoE Out Ports
Omada

ER603WP-4G-OUTDOOR - Omada ER603WP-4G-OUTDOOR 4G Cat4 N300 Outdoor PoE Gateway Router with 2x PoE Out Ports

SKU: ER603WP-4G-OUTDOOR ● In Stock
$339.00
Free shipping over $299 Genuine product 7-day returns

ER603WP-4G-OUTDOOR

ER603WP-4G-OUTDOOR - Omada ER603WP-4G-OUTDOOR 4G Cat4 N300 Outdoor PoE Gateway Router with 2x PoE Out Ports

Description

Omada ER603WP-4G-OUTDOOR 4G Cat4 N300 Outdoor PoE Gateway Router with 2x PoE Out Ports.

The Omada ER603WP-4G-Outdoor is a multi-functional 4G gateway, specifically engineered for remote surveillance systems. Its integrated PoE-Out is designed to directly power IP cameras, dramatically simplifying installation by eliminating the need for separate power sources. It leverages dependable LTE performance for constant connectivity, with load balancing to optimize bandwidth and automatic 4G failover to guarantee uninterrupted coverage in any scenario. Housed in a rugged IP55-rated enclosure and fully compatible with the Omada SDN platform for centralized cloud management, it is the ideal, multi-functional solution for installers and MSPs deploying resilient IP camera networks in challenging environments like construction sites, farms, or remote facilities.
Features
  • 4G Cat4 up to 150 Mbps
  • Wi-Fi 4, Support 300 Mbps on 2.4 GHz
  • 3× Gigabit WAN/LAN Ports (2× PoE Out, 1× PoE In)
  • 1× Nano SIM Card Slot
  • 802.3af/at/bt PoE/Passive PoE/DC Power Supply
  • IP55 Weatherproof & 4 kV Lightning Protection
  • Load Balancing between 4G and Ethernet WAN
  • IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE VPN
  • Centralized Cloud Management‡
  • Wall/Pole Mounting

Specifications

Details
Manufacturer's Code ER603WP-4G-OUTDOOR
Standards and Protocols IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE 802.3x, IEEE 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP, LLDP, 802.11b/g/n
Interface 3 Gigabit WAN/LAN Ports
LTE 1 Nano SIM slot (CAT4 4G)
LTE Speed Downlink: 150 Mbps, Uplink: 50 Mbps
Wi‑Fi Speed 2.4 GHz: 300 Mbps
Antennas 2 internal Wi‑Fi antennas; 2 external LTE antennas
Network Media 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m); EIA/TIA-568 100Ω STP (Max 100 m); 100BASE-TX: UTP category 5, 5e cable (Max 100 m); EIA/TIA-568 100Ω STP (Max 100 m); 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
PoE Standard Passive/802.3af/at/bt PoE in for port 1; Passive/802.3af/at PoE out for port 2-3
PoE Power Budget 52 W when powered by 802.3bt Type 4 (90 W); 34 W when powered by 802.3bt Type 3 (60 W); 13 W when powered by 802.3at (30 W); 9 W when powered by Passive
Network Type 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700); 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz); 3G HSPA+/HSDPA/HSUPA/WCDMA: B1/B5/B8 (2100/850/900 MHz)
Button Reset button
Power Supply Passive/802.3af/at/bt PoE or 12V/1A Adapter
Flash 128 MB NAND
DRAM 256MB DDR3
LED 4G Signal, WLAN, WAN/LAN, SYS
Max Power Consumption 10 W without PoE; 62 W with PoE
Surge Protection 4 kV surge protection
Mounting Wall-mounting; Pole-mounting
Dimensions 100.4 × 38.7 × 174.8 mm
Net Weight 0.420 kg
MTBF 889200 h@25°C; 510826 h@40°C
SDN Support Hardware Controller; Automatic Device Discovery; Intelligent Network Monitoring; Abnormal Event Warnings; Unified Configuration; Reboot Schedule; Captive Portal Configuration; ZTP (Zero-Touch Provisioning); Software Controller; Omada App
Certifications CE, RoHS
Operating Temperature -30°C to 60°C
Storage Temperature -40°C to 70°C
Operating Humidity 5% to 95% non-condensing
Storage Humidity 5% to 90% non-condensing
