ES205GP - Omada ES205GP SDN 5-Port Gigabit PoE Switch with 4-Port PoE+
Omada

ES205GP - Omada ES205GP SDN 5-Port Gigabit PoE Switch with 4-Port PoE+

SKU: ES205GP ● In Stock
$97.99
Free shipping over $299 Genuine product 7-day returns
  • ✅ 5× 10/100/1000Mbps RJ45 ports (4× 802.3at/af-compliant PoE+)
  • ✅ 65W Power Budget, with up to 30W for each PoE port*
  • ✅ Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
  • ✅ Centralized Cloud Management via the web or the Omada app†
  • ✅ Up to 250m PoE**, QoS△, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networking
  • ✅ Automatic Loop Prevention, VLAN, and IGMP Snooping
  • ✅ Fanless design for silent operation
  • ✅ Durable metal casing and desktop/wall mounting design
Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

- Easy to Use
- Hardware, Software, or Cloud-Based Controllers
- Centralized Management via Web or Omada App
- Zero-Touch Provisioning (ZTP)


Abundant Functions for Reliable Surveillance Networking
- Transmission Distance up to 250 m
- Priority Video Quality Guaranteed
- Secure Traffic Separation via Port Isolation
- PoE Auto Recovery

Multiple Application Scenarios

Surveillance
Works with IP Cameras

Conference Call
Works with IP Phones

Wi-Fi Coverage
Works with Access Points

Wired Connections
Works with Non-PoE Devices such as PCs and Printers

Compact and Durable Metal Casing, Featuring Desktop/Wall Mounting and a Fanless Design

Technical Specifications

Switch type Managed
Quality of Service (QoS) support Y
Cloud-managed Y
Basic switching RJ-45 Ethernet ports quantity 5
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Networking standards IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.3at,IEEE 802.3x
10G support N
Port mirroring Y
Flow control support Y
Link aggregation Y
Auto MDI/MDI-X Y
Auto-negotiation Y
VLAN support Y
Virtual LAN features MTU VLAN,Port-based VLAN,Tagged VLAN
Transmission distance (max) 0.25
Switching capacity 10
Forwarding rate 7.4
MAC address table 8000
Store-and-forward Y
Jumbo frames support Y
Jumbo frames 15
Packet buffer memory 4
DHCP features DHCP client
IGMP snooping Y
Loop protection Y
Product colour Black
Reset button Y
LED indicators Y
Wall mountable Y
Fanless Y
Power source AC/DC
Power supply included Y
DC input voltage 53.5
Power over Ethernet (PoE) Y
Power over Ethernet (PoE) ports quantity 4
Power over Ethernet plus (PoE+) ports quantity 4
Power over Ethernet (PoE) power per port 30
Total Power over Ethernet (PoE) budget 65
Operating temperature (T-T) 0 - 40
Storage temperature (T-T) -40 - 70
Operating relative humidity (H-H) 10 - 90
Storage relative humidity (H-H) 5 - 90
Width 100
Depth 98
Height 25
User guide Y
Package type Box
Compliance certificates CE,Federal Communications Commission (FCC),RoHS
