Features
Ubiquiti LTU-Pro 5GHz LTU Client Radio with Advanced RF Performance. Incorporating innovative industrial design with advanced technology, the LTU Pro is a Point-to-MultiPoint (PtMP) 5 GHz high-performance subscriber station. Based on Ubiquiti's proprietary LTU technology, the LTU Pro is not impeded by the limitations of standard 802.11 Wi-Fi technology. It features an integrated high-gain dish for long range and high performance. Channel width flexibility (10/20/30/40/50 MHz) allows independent TX and RX channel frequency configurations anywhere within the radio band to avoid local interference.
Featuring an integrated 24 dBi dish antenna, the LTU Pro is a 5 GHz subscriber station that functions as a CPE (Customer Premises Equipment) in a Point-to-MultiPoint (PtMP) environment with the LTU Rocket as the basestation.
- PtMP CPE for LTU-Rocket Base Station
- 1024 QAM
- 10/20/30/40/50 MHz channel bandwidth
- Central configuration management from AP side
- Frequency split
- Automatic power adjustments
- Router mode support
Specifications
Technical Specifications
| Dimensions | 316.5 x 316.5 x 174.3 mm(12.46 x 12.46 x 6.86") |
|---|---|
| Weight | 1.3 kg(2.87 lb) |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| Enclosure | Outdoor UV Stabilized Plastic |
| Max. Power Consumption | 9W |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Power Method | 24V Passive PoE (Pairs 4, 5+; 7, 8-) |
| Voltage Range | 22 -26V |
| Max. Conducted TX Power | 22 dBm (per Chain) |
| Gain | 24 dBi |
| Beamwidth | 14° |
| Sidelobe Level | -10 dB |
| Front-to-Back Ratio | 27 dB |
| Mounting | Pole-Mount (Kit Included) |
| Wind Loading | 150 N @ 200 km/h(33.72 lbf @ 125 mph) |
| Wind Survivability | 200 km/h(125 mph) |
| ESD/EMP Protection | ± 24kV Contact/Air |
| Operating Temperature | -5 to 40° C(23 to 104° F) |
| Operating Humidity | 10 -90% Noncondensing |
| Certifications | CE, FCC, IC |
