Yealink 1203691 - MeetingDisplay75
Features
MeetingDisplay 65/75/86 Unified Meeting, Display Now
Yealink's MeetingDisplay for MTR System (MTR Display)
Comes with a 3-year warranty.
INSTALL LIKE A BREEZE
The customized installation structure* makes installation easy, without the trouble of wall drilling. Just screw and hang, the meetingbar and display are ready!
ONE WAY AS ALL COORDINATION
Integrated with Yealink MeetingDisplay, Yealink unified solution supports automatic switching to current input source (regardless of which source you are on, when a Teams call comes in, it will automatically switch to Teams), as well as sleep and wake-up functionality. Enjoy smooth and seamless meeting device coordination.
ONE TOUCH CONSOLE, GET TO THE HEART OF CONFIGURATION FAST.
One touch console is enough. Configure MTR devices and MeetingDisplay easily, without TV remote control. Effortlessly switch signal inputs and adjust Meeting-Display's brightness, contrast, volume, etc.
MANAGEMENT OVER THE AIR
With Yealink Management Cloud Service (YMCS), you can manage both MeetingDisplay and MTR devices from a single platform - no need to switch between systems.
Manage Devices in Bulk
Upgrade and update phones in bulk by specifying firmware and resources.
Get Real-time Alarms
There are multiple alarms such as poor call quality and firmware upgrade failure. Set notification emails to ensure IT admins won't miss any alarms.
Schedule Tasks Worry Free
Implement management tasks during off-hours to ensure business continuity, and view the execution results of each task to provide you with peace of mind.
CONNECT. SHARE. ENGAGE.
The MeetingDisplay features a Dual-Ethernet design, with one port capable of providing network connectivity for MTR devices-solving the issue of limited Ethernet availability. It also supports seamless wireless content sharing via presentation pod, enabling effortless local collaboration. Additionally, near-zero latency HDMI-in ensures smooth, lag-free communication.
(Note: Wireless presentation pod is unavailable in the USA)
For more information: https://www.yealink.com/en/product-detail/meetingdisplay
Specifications
Technical Specifications
| Screen Size: | 75 inch |
|---|---|
| Display Type: | IPS |
| Surface Treatment: | Anti-glare Coating |
| Refresh Rate: | 60Hz |
| Grayscale Response Time: | 8ms |
| Color Gamut: | 72% NTSC |
| Colour Depth: | 1.07G (10bit) |
| Viewing Angle: | 178°(H)/178°(V) |
| Contrast Ratio: | 1200: 1 |
| Resolution: | 3840 x 2160 |
| Brightness: | 500 cd/㎡ |
| Haze: | 25% |
| Operation Time: | 7*18h |
| Speaker: | 12W x 2 |
| Wired screen sharing: | - HDMI In |
| Wireless screen sharing: | - AirPlay- Miracast- Wireless Presentation Pod (unavailable in the United States) |
| Video: | HDMI In 2.0 x 3 |
| Audio: | 3.5mm Stereo Mini Jack (Output) |
| USB: | USB- A 2.0 x 2, USB- B 2.0 x 1 |
| LAN: | 2x RJ45 10/100/1000M network ports |
| Control: | RS232 x 1, IP Control（Via LAN） |
| Others: | Reset x 1 |
| WiFi: | Wi-Fi 6- 2.4G & 5G dual-band, 802.11a/b/g/n/ac/ax |
| Bluetooth: | Bluetooth 5.1 |
| IR: | Supported |
| Methods | Wall-mounted InstallationFloor-stand Installation |
| Items included | 1 x MeetingDisplay1 x Cable Pack- 1 x 3m AC power cable- 1 x 3m CAT5E network cable- 1 x Quick Start Guide- Cable ties- 1 x Remote Controller (IR)- 2 x AAA Batteries- 1 x MCore bracket (Compatible with MCore 4, MCore 4 is sold separately) |
| Mounting Accessories for MeetingDisplay: | Wall mounting Bracket: MD-WallMount (Suitable for 65", 75", and 86" MeetingDisplay)Motorized mobile stand: MB-FS-Lift |
| Mounting Accessories for MVC Series & MeetingBar: | Mounting Bracket:- MD-AVBracket- S: Compatible with MeetingBar A40, SmartVision 40, MSpeaker Pro- MD-AVBracket- L: Compatible with MeetingBar A50- MD-PTZBracket: Compatible with UVC86 |
| Casting Accessories: | Wireless Presentation Pod (unavailable in the United States) |
| Operating System: | Android 13 |
| Storage | - Memory: 4G- Flash: 32G |
| Power Adapter: | 100- 240V~50/60Hz |
| Power Consumption: | - Max: 215W- Typical: 186W- Off mode: less than 0.5W |
| Operating Temperature: | 0~40°C |
| Storage Temperature: | -20~60°C |
| Operating Humidity: | 10~95% |
| Warranty | 3 - year |
| Bare Device Dimensions (W × D × H) | 1680 x 57 x 959mm |
| Packaging Dimensions (W × D × H) | 1815 x 185 x 1055mm |
| Net Weight | 28.4kg (62.6 lbs) |
| Gross Weight | 38.7kg (85.3 lbs) |
| VESA Hole Specs | 600 x 400mm |
| VESA Mount Screw | M8 |
| Bezel Width | 6/6/6/8.5(L/R/U/D) |
| Brand | Yealink |
|---|---|
| Product Type | TV & Home Theatre > Digital Signage |
| Weight | 17.551 kg |
| Warranty |
|---|
