SG2428P - TP-Link SG2428P Omada SDN 24 Port Gigabit Smart Switch PoE+

Overview

TP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.

24× Gigabit 802.3af/at PoE+ ports and 4× Gigabit SFP slots
250 W total PoE budget with up to 30 W PoE output per port*
Centralized cloud management via the web or the Omada app†
Standalone management via web, CLI, SNMP, and RMON
Static Routing helps route internal traffic for higher efficiency
VLAN, ACL, QoS, and IGMP Snooping
Durable metal casing and rackmountable design

Technical Specifications

Switch type	Managed
Switch layer	L2/L2+
Quality of Service (QoS) support	Y
Web-based management	Y
ARP inspection	Y
System event log	Y
MIB support	Y
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	24
SFP module slots quantity	4
Networking standards	IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support	N
Copper ethernet cabling technology	10BASE-T,1000BASE-T
Cable types supported	Cat3,Cat4,Cat5,Cat5e
Port mirroring	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Rate limiting	Y
Spanning tree protocol	Y
VLAN support	Y
Virtual LAN features	MAC address-based VLAN,Protocol-based VLAN,Voice VLAN
Number of VLANs	4000
Fiber ethernet cabling technology	1000BASE-X
Switching capacity	56
Forwarding rate	41.66
MAC address table	8000
Number of queues	8
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	4.1
DHCP features	DHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 client
Access Control List (ACL)	Y
IGMP snooping	Y
Security algorithms	HTTPS,SNMP,SNMPv2,SNMPv3,SSH,SSH-2,SSL/TLS
SSH/SSL support	Y
BPDU filtering/protection	Y
IP-MAC-Port binding	Y
Authentication type	RADIUS
Queue scheduling algorithms	SP,WRR+SP,Weighted Round Robin (WRR)
Multicast support	Y
Management protocols	SNMPv1/v2c/v3, SNTP
Rack mounting	Y
Form factor	1U
Product colour	Black
Number of fans	2
Firmware upgradeable	Y
Power source	AC
Power supply included	Y
AC input voltage	100 - 240
AC input frequency	50/60
Power consumption (max)	301.1
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	24
Power over Ethernet (PoE) power per port	30
Total Power over Ethernet (PoE) budget	250
Operating temperature (T-T)	0 - 50
Storage temperature (T-T)	-40 - 70
Operating relative humidity (H-H)	10 - 90
Storage relative humidity (H-H)	5 - 90
Heat dissipation	1052.94
Width	440
Depth	220
Height	44
Cables included	AC
User guide	Y
Rack mount kit	Y
Certification	CE, FCC, RoHS
